Atdec AWMS-1340 Single Monitor Arm Mount on Post for POS & Touchscreens
The Atdec AWMS-1340 is a professional-grade single monitor arm mount designed specifically for point of sale (POS) and point of service applications in retail, medical, and hospitality environments. Featuring a 130mm short swing arm attached to a 400mm medium post, this mount delivers exceptional ergonomics and space-saving design while supporting displays up to 12kg (26.5lb) flat or 10kg (22lb) curved screens including all-in-one devices and touchscreens.
Key Features
-
Heavy-duty capacity: Supports flat screens up to 12kg (26.5lb) or curved/deep screens up to 10kg (22lb)
-
Ergonomic tilt range: Large tilt adjustment from -15° to +40° for optimal touchscreen ergonomics
-
Bolt-through desk fixing: Secure installation with bolt-through mounting system
-
Modular design: Part of Atdec's modular range for easy upgrades and reconfiguration
-
Handsfree drop-on VESA: Quick and easy installation with tool-free VESA attachment
-
Advanced cable management: Integrated cable routing keeps workspaces tidy
Perfect for Professional Environments
The AWMS-1340 excels in demanding commercial settings where reliability and ergonomics are critical. The 400mm (15.7") post height provides vertical positioning flexibility, while the short 130mm swing arm delivers compact lateral movement without sacrificing adjustability. The small footprint saves valuable counter space, making it ideal for POS terminals, medical workstations, and hospitality check-in desks.
Installation & Adjustability
Designed with installers in mind, the AWMS-1340 features a handsfree drop-on VESA design that simplifies screen attachment and removal. The bolt-through desk fixing provides superior stability for touchscreen applications where users interact directly with the display. The generous -15° to +40° tilt range ensures comfortable viewing angles whether users are standing or seated, particularly important for POS touchscreens.
Modular & Future-Proof
As part of Atdec's innovative modular mounting system, the AWMS-1340 can be easily upgraded or reconfigured as your needs evolve. Components can be swapped or added without replacing the entire mounting solution, providing long-term value and flexibility for changing workspace requirements.
What's in the Box
- 1 × AWM-A13T-B short swing arm (130mm, black)
- 1 × AWM-P40G-B medium post (400mm, black, with guide marks)
- 1 × Bolt-through desk fixing (black)
- Installation hardware and instructions
Full Specifications
| Model |
AWMS-1340 (Black finish) |
| Arm Length |
130mm short swing arm |
| Post Height |
400mm (15.7") |
| Maximum Load Capacity |
12kg (26.5lb) flat screens / 10kg (22lb) curved or deep screens |
| Tilt Range |
-15° to +40° |
| Pan Adjustment |
Yes |
| VESA Compatibility |
Standard VESA mount patterns |
| Mounting Type |
Bolt-through desk fixing |
| Cable Management |
Advanced integrated cable routing |
| Finish |
Black powder coat |
| Warranty |
10 years |
| Ideal Applications |
POS, retail, medical, hospitality, touchscreen workstations |
Specifications are sourced from the manufacturer product page and may be updated.
