D-Link DES-F1010P-E 10-Port Long Range PoE+ Switch with 250m Extended Range
The D-Link DES-F1010P-E is a high-performance 10-port Fast Ethernet PoE+ switch designed specifically for IP surveillance and small business networks. Featuring 8 PoE+ ports and 2 uplink ports, this unmanaged switch delivers a 96W total PoE budget and supports extended cable runs up to 250 meters, making it ideal for deploying IP cameras, wireless access points, and VoIP phones in remote locations without nearby power outlets.
Why Choose the DES-F1010P-E?
-
Long Range PoE Technology: Extends PoE transmission up to 250m using Cat5e or Cat6 cable, perfect for large surveillance deployments
-
96W PoE Budget: Supports IEEE 802.3af/at standards with up to 30W per port for powering multiple PoE devices simultaneously
-
6kV Lightning Protection: Built-in surge protection safeguards your network against electrical surges and lightning strikes
-
Flexible DIP Switch Modes: Choose from Extend, VLAN, QoS, or PoE Reset modes to optimize performance for your specific application
-
Plug-and-Play Installation: No configuration required for hassle-free setup in minutes
-
Fanless Silent Operation: Compact metal housing with fanless design for noise-sensitive environments
Extended Range PoE for Surveillance and Remote Installations
The standout feature of the DES-F1010P-E is its ability to deliver power and data over distances up to 250 meters when Extend Mode is enabled via the DIP switch. This is 2.5 times the standard 100m Ethernet limit, making it perfect for positioning IP cameras and wireless access points in locations far from network closets or power sources. Whether you're setting up a warehouse surveillance system, outdoor campus network, or large retail environment, the long range capability simplifies installation and reduces cabling costs.
Smart DIP Switch Modes
Configure the switch for your specific needs using the convenient DIP switch:
-
Extend Mode: Enables 250m PoE transmission on ports 1-8 (recommended with Cat5e or Cat6 cable)
-
VLAN Mode: Isolates ports 1-8 from each other while allowing uplink communication, suppressing network storms and improving security
-
QoS Mode: Prioritizes video traffic for smoother surveillance transmission and better performance
-
PoE Reset Mode: Automatically detects unresponsive PoE devices and reboots them to maintain network reliability
Power Over Ethernet – Simplified Deployment
With 8 PoE+ ports supporting IEEE 802.3af/at standards, the DES-F1010P-E can deliver up to 30W per port with a 96W total power budget. Connect and power IP cameras, wireless access points, VoIP phones, and other PoE-capable devices without the need for separate power adapters. This dramatically simplifies installation, reduces cable clutter, and enables device placement in locations without convenient electrical outlets.
Built for Reliability
The DES-F1010P-E is engineered for dependable operation in demanding environments. 6kV surge protection guards against electrical damage from lightning strikes and power fluctuations, minimizing downtime and repair costs. The fanless metal enclosure ensures silent operation while providing durability and effective heat dissipation. IEEE 802.3x flow control prevents packet loss during peak traffic periods, ensuring reliable data transmission for all connected devices.
Universal Connectivity
- 8 × 10/100BASE-T PoE+ ports (IEEE 802.3af/at, up to 30W per port)
- 2 × 10/100BASE-T uplink ports
- Auto MDI/MDIX crossover on all ports
- Auto-negotiation for optimal speed and duplex mode
Ideal Applications
- IP surveillance camera systems with remote camera placement
- Wireless access point deployment in large buildings
- VoIP phone systems for small offices
- Retail, warehouse, and industrial network installations
- Campus and outdoor network extensions
What's in the Box
- DES-F1010P-E 10-Port Long Range PoE+ Switch
- External power adapter (96W)
- Quick installation guide
Full Specifications
| Model |
DES-F1010P-E |
| Ports |
8 × 10/100BASE-T PoE+ ports
2 × 10/100BASE-T uplink ports |
| PoE Standards |
IEEE 802.3af (PoE)
IEEE 802.3at (PoE+) |
| PoE Budget |
96W total
Up to 30W per port |
| Extended Range |
Up to 250m in Extend Mode (Cat5e/Cat6) |
| Data Transfer Rate |
10 Mbps (Ethernet)
100 Mbps (Fast Ethernet) |
| Switching Capacity |
2 Gbps |
| Packet Filtering Rate |
10M port: 14,800 pps
100M port: 148,800 pps |
| Transmission Method |
Store-and-forward |
| Network Standards |
IEEE 802.3 10BASE-T
IEEE 802.3u 100BASE-TX
IEEE 802.3x flow control
ANSI/IEEE 802.3 NWay auto-negotiation |
| DIP Switch Modes |
Extend, VLAN, QoS, PoE Reset |
| Lightning Protection |
6kV surge protection |
| LEDs |
Power, Link/Activity per port |
| Form Factor |
Desktop, fanless metal housing |
| Dimensions |
184 × 75 × 27 mm |
| Weight |
0.95 kg |
| Power Input |
External 96W power adapter |
| Operating Temperature |
0 to 40°C (32 to 104°F) |
| Storage Temperature |
-10 to 70°C (14 to 158°F) |
| Operating Humidity |
10% to 90% non-condensing |
| Storage Humidity |
5% to 90% non-condensing |
Specifications are sourced from the manufacturer product page and may be updated.
