D-Link DGS-1010P 10-Port Gigabit Unmanaged PoE+ Switch
The D-Link DGS-1010P is a plug-and-play 10-port Gigabit unmanaged PoE+ switch designed to deliver reliable power and high-speed connectivity for small offices, home networks, and IP surveillance systems. With 8 Gigabit PoE+ ports supporting IEEE 802.3at, this switch provides up to 30W per port with a 125W total power budget, allowing you to power IP cameras, wireless access points, VoIP phones, and other PoE-enabled devices without the need for additional power supplies. The fanless design ensures silent operation, while 2 SFP uplink ports extend network reach beyond 100 meters for flexible deployment in business and surveillance environments across Australia.
Why Choose the D-Link DGS-1010P?
-
Plug-and-Play Installation: No configuration required – simply connect your devices and start working immediately
-
High PoE Budget: 125W total budget powers up to 4 IEEE 802.3at devices simultaneously at full 30W per port
-
Extended Network Reach: 2 SFP uplink ports for fiber connections beyond 100-meter copper Ethernet limitations
-
Advanced DIP Switch Controls: Easily toggle port isolation, flow control, QoS, and extend mode without complicated configuration
-
Silent Operation: Fanless design for noise-free performance in offices, classrooms, and home environments
-
Energy Efficient: IEEE 802.3az Energy-Efficient Ethernet reduces power consumption during low network utilization
Ideal for IP Surveillance and Business Networks
The DGS-1010P is perfect for connecting and powering IP cameras for CCTV surveillance systems, making it ideal for small businesses, retail stores, offices, and home security setups. The 802.1p Quality of Service (QoS) feature automatically organizes and prioritizes time-sensitive data, ensuring buffer-free video streaming and smooth transmission for surveillance footage, video calls, and VoIP communications. Deploy wireless access points, security cameras, and VoIP phones anywhere without needing nearby power outlets, dramatically reducing installation costs and cable clutter.
Flexible Network Configuration
Unlike traditional unmanaged switches, the DGS-1010P includes DIP switch controls that allow you to instantly adjust critical settings on-site. Toggle between port isolation mode for enhanced security, flow control for optimized data transmission, storm control to prevent network flooding, and extend mode for longer-range PoE delivery. These features give you managed-switch flexibility without the complexity, making the DGS-1010P the ideal choice for small businesses that need adaptability without IT expertise.
Universal Gigabit Connectivity
-
8 × 10/100/1000 Mbps PoE+ ports (IEEE 802.3at) with up to 30W per port
-
2 × Gigabit SFP uplink ports for fiber optic connections and network expansion
-
Auto MDI/MDI-X eliminates the need for crossover cables
-
Auto-negotiation on all ports for seamless 10/100/1000 Mbps speed detection
-
Store-and-forward switching maximizes network performance and minimizes packet loss
Energy-Saving Green Technology
The DGS-1010P supports IEEE 802.3az Energy-Efficient Ethernet (EEE), which automatically reduces power consumption when network utilization is low. By using EEE-compliant devices, the switch intelligently puts ports into sleep mode during periods of inactivity, noticeably reducing operating costs and environmental impact. This makes the DGS-1010P an eco-friendly choice for Australian businesses looking to minimize their energy footprint.
Compact and Versatile Design
The switch features a compact desktop form factor that can be placed anywhere in your workspace, avoiding excessive cable clutter while powering multiple PoE devices. The fanless design guarantees a quiet working environment, making it suitable for noise-sensitive areas like offices, meeting rooms, classrooms, and home offices. Whether you're expanding an existing network or building a new one, the DGS-1010P provides reliable performance in a space-saving package.
What's in the Box
- D-Link DGS-1010P 10-Port Gigabit PoE+ Switch
- Power adapter
- Mounting kit
- Quick installation guide
Full Specifications
Hardware
| Total Ports |
10 ports (8 PoE+ ports + 2 SFP uplink ports) |
| PoE Ports |
8 × 10/100/1000BASE-T PoE+ ports |
| Uplink Ports |
2 × Gigabit SFP ports |
| PoE Standard |
IEEE 802.3at (PoE+) |
| Power per Port |
Up to 30W per port |
| Total PoE Budget |
125W |
| Switching Fabric |
20 Gbps |
| Cooling |
Fanless design (silent operation) |
Performance
| Port Standards |
IEEE 802.3i 10BASE-T, IEEE 802.3u 100BASE-TX, IEEE 802.3ab 1000BASE-T |
| Data Transfer Rates |
10/100/1000 Mbps auto-negotiation |
| Packet Forwarding Rate |
14.88 Mpps (1,488,000 pps per Gigabit port) |
| Auto MDI/MDI-X |
Yes (all ports) |
| Flow Control |
IEEE 802.3x (configurable via DIP switch) |
| Quality of Service |
802.1p QoS for prioritized data delivery |
Features
| Management Type |
Unmanaged with DIP switch configuration |
| DIP Switch Features |
Port isolation, flow control, storm control, extend mode |
| Port Isolation |
Yes (via DIP switch) |
| Storm Control |
Yes (via DIP switch) |
| Extend Mode |
Supports extended PoE and data transmission beyond 100m |
| Energy Efficiency |
IEEE 802.3az Energy-Efficient Ethernet (EEE) |
Physical
| Dimensions |
Compact desktop design |
| Form Factor |
Desktop |
| LED Indicators |
Power, Link/Activity, PoE, Speed |
Power
| Input Voltage |
100-240V AC, 50/60 Hz (external power adapter) |
| Maximum Power Consumption |
Varies based on PoE load (125W PoE budget + switching overhead) |
Environmental
| Operating Temperature |
0°C to 40°C |
| Storage Temperature |
-40°C to 70°C |
| Operating Humidity |
10% to 90% non-condensing |
| Storage Humidity |
5% to 95% non-condensing |
Specifications are sourced from the manufacturer product page and may be updated.
