D-Link DGS-1010P 10-Port Gigabit Unmanaged PoE+ Switch
The D-Link DGS-1010P is a powerful plug-and-play 10-port Gigabit unmanaged PoE+ switch designed to simplify network deployment for small businesses, surveillance systems, and office environments. Featuring 8 Gigabit PoE+ ports and 2 SFP uplink ports, this fanless switch delivers up to 30W per port with a generous 125W total power budget, allowing you to connect and power PoE-enabled devices such as IP cameras, wireless access points, VoIP phones, and displays without the need for additional power supplies.
Key Features
-
8 Gigabit PoE+ Ports: IEEE 802.3at compliant, delivering up to 30W per port for high-powered devices
-
125W Total PoE Budget: Power multiple PoE devices simultaneously with confidence
-
2 SFP Uplink Ports: Extend Gigabit transmission beyond 100 meters using fiber optic connections
-
Plug-and-Play Installation: No configuration required, just connect and power on
-
Fanless Design: Silent operation perfect for noise-sensitive environments like offices and meeting rooms
-
DIP Switch Control: Easily toggle flow control, port isolation, storm control, and extend mode settings
-
802.1p Quality of Service (QoS): Automatically prioritizes time-sensitive data for buffer-free video streaming and clear voice calls
-
Energy Efficient Ethernet (EEE): IEEE 802.3az compliant for reduced power consumption during low network utilization
Perfect for Surveillance & Business Networks
The DGS-1010P is ideal for IP camera installations, allowing you to deploy surveillance systems without worrying about separate power outlets for each camera. The PoE+ standard ensures compatibility with the latest high-definition IP cameras, PTZ cameras, wireless access points, and other demanding network devices. The two SFP uplink ports provide network flexibility and scalability, enabling long-distance fiber connections to aggregation or core network layers.
Simple Management with DIP Switches
Unlike traditional unmanaged switches, the DGS-1010P features DIP switch controls that allow you to make onsite adjustments to advanced features without accessing web interfaces. Toggle settings for flow control to prevent packet loss, port isolation to enhance security by preventing ports from communicating with each other, storm control to protect against broadcast storms, and extend mode to push PoE power and data beyond the standard 100-meter Ethernet limitation.
Flexible Connectivity Options
With 8 Gigabit Ethernet PoE+ ports for connecting powered devices and 2 Gigabit SFP ports for fiber uplink connections, the DGS-1010P offers versatile deployment options. The SFP ports support both multimode and singlemode fiber transceivers, making it easy to integrate the switch into existing network infrastructure or extend your network across longer distances where copper cabling isn't practical.
Energy Efficient & Cost-Effective
Built with IEEE 802.3az Energy-Efficient Ethernet technology, the DGS-1010P automatically reduces power consumption when network utilization is low, lowering operating costs without sacrificing performance. The fanless design not only ensures silent operation but also eliminates moving parts that can fail, increasing reliability and reducing maintenance requirements.
Ideal Applications
- IP surveillance camera systems with up to 8 PoE cameras
- Small business networks requiring wireless access point deployment
- VoIP phone systems for offices
- Digital signage and display installations
- Educational institutions and training facilities
- Retail environments with PoE-powered devices
What's in the Box
- D-Link DGS-1010P Switch
- Power adapter
- Rack mount kit
- Quick installation guide
Full Specifications
| Model |
DGS-1010P |
| Port Configuration |
8 × 10/100/1000 Mbps Gigabit Ethernet PoE+ ports
2 × Gigabit SFP uplink ports |
| PoE Standard |
IEEE 802.3at (PoE+) and 802.3af (PoE) |
| PoE Power Budget |
125W total
30W maximum per port |
| Switching Capacity |
20 Gbps |
| Packet Forwarding Rate |
14.88 Mpps |
| Standards Compliance |
IEEE 802.3i 10BASE-T
IEEE 802.3u 100BASE-TX
IEEE 802.3ab 1000BASE-T
IEEE 802.3z Gigabit SFP
IEEE 802.3x Flow Control
IEEE 802.3az Energy-Efficient Ethernet
IEEE 802.1p Quality of Service |
| MAC Address Table |
8K entries |
| Buffer Memory |
128 KB per device |
| Jumbo Frame Support |
Yes |
| Special Features |
DIP switch controls for flow control, port isolation, storm control, and extend mode
Auto MDI/MDIX on all ports
Store-and-forward switching |
| Operating Temperature |
0°C to 40°C (32°F to 104°F) |
| Storage Temperature |
-40°C to 70°C (-40°F to 158°F) |
| Operating Humidity |
10% to 90% (non-condensing) |
| Cooling |
Fanless (silent operation) |
| Power Input |
100-240V AC, 50/60Hz (external power adapter) |
| Certifications |
FCC, CE, RCM |
Specifications are sourced from the manufacturer product page and may be updated.
