D-Link DGS-1100-24V2 24-Port Gigabit Smart Managed Network Switch
The D-Link DGS-1100-24V2 is a powerful smart managed switch designed for small to medium-sized businesses that demand high-performance networking with advanced management features. Featuring 24 Gigabit Ethernet ports with a 48 Gbps switching capacity and 35.71 Mpps forwarding rate, this switch delivers reliable, high-speed connectivity for devices like computers, servers, IP cameras, and network storage. Its fanless design ensures silent operation while D-Link Green technology reduces power consumption, making it an energy-efficient and cost-effective networking solution for Australian businesses.
Key Features
-
24 Gigabit Ethernet Ports: 10/100/1000 Mbps auto-sensing ports with Auto MDI/MDIX for seamless connectivity
-
High Performance: 48 Gbps switching capacity and 35.71 Mpps maximum forwarding rate
-
Silent Operation: Fanless design operates at 0 dB for quiet, energy-efficient performance
-
Energy Efficient: IEEE 802.3az Energy Efficient Ethernet compliant with link status detection
-
Easy Management: Web-based interface and D-Link Network Assistant (DNA) utility for streamlined setup
-
Advanced Traffic Control: VLAN support, QoS, bandwidth control, and IGMP snooping
Advanced Layer 2 Management
The DGS-1100-24V2 provides comprehensive Layer 2 switching features including port-based and 802.1Q tagged VLANs (up to 128 static VLAN groups), Spanning Tree Protocol (STP/RSTP), and link aggregation. Surveillance VLAN gives video traffic high priority for IP camera deployments, while Voice VLAN ensures smooth VoIP performance. The switch supports IGMP Snooping (v1/v2/v3) with up to 64 groups, sending multicast traffic only where needed to reduce network congestion.
Security and Network Protection
Equipped with advanced security features, the switch includes Static MAC address control, Storm Control for broadcast/multicast/unknown unicast traffic, and D-Link Safeguard Engine to protect against traffic flooding and attacks. Traffic segmentation and flexible VLAN configurations heighten network security by isolating different types of traffic.
Intelligent Network Diagnostics
The DGS-1100-24V2 features Loopback Detection to automatically detect and shut down ports creating network loops, plus Cable Diagnostics to quickly examine copper cable quality, recognise cable types, and detect errors. These troubleshooting tools help network administrators identify and resolve network problems quickly, minimising downtime.
Quality of Service and Bandwidth Control
With 802.1p Quality of Service and 4 queues per port, the switch prioritises latency-sensitive traffic for timely delivery of voice and video applications. Port-based bandwidth control (ingress 8 Kbps, egress 64 Kbps minimum) reserves bandwidth for critical functions, ensuring important applications always get the resources they need.
Energy Savings with D-Link Green Technology
The DGS-1100-24V2 implements D-Link Green technology that automatically monitors link status and significantly reduces power consumption when ports have no link or network traffic. Typical power consumption is just 10.37W, with maximum consumption of 13.94W. Combined with IEEE 802.3az Energy Efficient Ethernet, this switch helps Australian businesses reduce operating costs and environmental impact.
Flexible Installation Options
With desktop or 19-inch rackmount placement options (rackmount brackets included) and a compact 1U height design, the switch fits easily into server racks or can sit on a desktop. Its 11-inch form factor is ideal for smaller rack installations.
What's in the Box
- D-Link DGS-1100-24V2 switch
- Rackmount brackets
- Power adapter (100-240V AC)
- Quick installation guide
Full Specifications
Hardware
| Model |
DGS-1100-24V2 |
| Hardware Version |
Ax |
| Number of Ports |
24 × 10/100/1000 Mbps Gigabit Ethernet |
| Port Standards |
IEEE 802.3 Ethernet, IEEE 802.3u Fast Ethernet, IEEE 802.3ab Gigabit Ethernet, IEEE 802.3az EEE, IEEE 802.3x Flow Control |
| Mounting Options |
Desktop or 19-inch rack mount (brackets included), 1U height |
| Dimensions (W × D × H) |
280 × 180 × 44 mm |
| Weight |
1.47 kg |
Performance
| Switching Capacity |
48 Gbps |
| Maximum Forwarding Rate |
35.71 Mpps |
| Switching Method |
Store-and-forward |
| MAC Address Table |
8,000 entries |
| Jumbo Frames |
Up to 9,216 bytes |
| MTBF |
2,406,109 hours |
Layer 2 Features
| VLAN Support |
Port-based VLAN, 802.1Q tagged VLAN, Auto Surveillance VLAN, Voice VLAN, Management VLAN, Asymmetric VLAN |
| VLAN Groups |
128 static VLAN groups, max 4094 VIDs |
| Flow Control |
802.3x Flow Control, HOL blocking prevention |
| IGMP Snooping |
IGMP v1/v2/v3 awareness, supports 64 groups, IGMP Snooping Querier |
| Link Aggregation |
802.3ad, max 8 groups per device, 8 ports per group |
| Spanning Tree Protocol |
802.1D STP, 802.1w RSTP |
| Port Mirroring |
One-to-one, many-to-one |
| LLDP |
Yes |
Quality of Service
| QoS |
802.1p Quality of Service, 4 queues per port |
| Queue Handling |
Strict, Weighted Round Robin (WRR) |
| Bandwidth Control |
Port-based ingress (8 Kbps min), egress (64 Kbps min) |
Security
| Security Features |
D-Link Safeguard Engine, Traffic Segmentation, Static MAC, Storm Control (broadcast/multicast/unknown unicast) |
Diagnostics
| Loopback Detection |
Yes |
| Cable Diagnostics |
Yes |
| Statistics |
Tx Ok, Tx Error, Rx Ok, Rx Error |
Management
| Management Interface |
Web-based GUI, D-Link Network Assistant (DNA) utility |
| Optional Management |
Nuclias Connect (cloud or on-premises) |
Power and Environment
| Power Input |
100 to 240V AC, 50/60 Hz (external adapter) |
| Typical Power Consumption |
10.37W |
| Maximum Power Consumption |
13.94W |
| Heat Dissipation |
47.57 BTU/hr |
| Acoustics |
0 dB (fanless design) |
| Operating Temperature |
0°C to 50°C |
| Storage Temperature |
-40°C to 70°C |
| Operating Humidity |
10% to 90% non-condensing |
| Storage Humidity |
5% to 95% non-condensing |
Standards and Certifications
| Certifications |
RoHS 6, cUL, CE LVD, CB, BSMI, CCC |
| Energy Efficiency |
IEEE 802.3az Energy Efficient Ethernet |
Memory
Specifications are sourced from the official manufacturer product page and may be updated.
