D-Link DGS-1210-08P 8-Port Gigabit Smart Managed PoE Switch with 2 SFP Ports
The D-Link DGS-1210-08P is a powerful and cost-effective smart managed switch designed for small to medium-sized businesses. Featuring 8 Gigabit PoE+ ports with a 65W power budget and 2 SFP fibre ports, this fanless switch delivers reliable network performance while powering IP cameras, VoIP phones, wireless access points, and other PoE devices without the need for separate power supplies.
Key Features
-
8 Gigabit PoE+ Ports: All 8 ports support IEEE 802.3af/at PoE with up to 30W per port, ideal for powering network devices remotely
-
65W Total PoE Power Budget: Ample power capacity for multiple PoE devices across your network
-
2 SFP Fibre Ports: Enable long-distance fibre optic connections for campus or multi-building deployments
-
Advanced Layer 2 Management: VLAN support, QoS, Link Aggregation (LACP), Spanning Tree Protocol (STP), and IGMP Snooping for optimised traffic management
-
Fanless Silent Operation: Perfect for quiet office environments with zero noise and reduced energy consumption
-
D-Link Green 3.0 Technology: Energy-efficient design with port shutoff, cable length detection, and time-based PoE scheduling to reduce power costs
Intelligent Network Management
The DGS-1210-08P features a web-based user interface for easy configuration and management, with support for Auto Surveillance VLAN and Auto Voice VLAN. These smart features automatically detect and segment IP surveillance cameras and VoIP devices onto dedicated high-priority VLANs, ensuring smooth video streaming and clear voice communication even during peak network traffic.
Built for Business Security
Protect your network with robust security features including 802.1X port-based authentication, Access Control Lists (ACLs), ARP spoofing prevention, DHCP server screening, and D-Link's innovative Safeguard Engine that defends against malicious traffic flooding and denial-of-service attacks.
Power Over Ethernet for Simplified Deployment
With IEEE 802.3af/at PoE+ compliance, the DGS-1210-08P can deliver both data and power over a single Ethernet cable to compatible devices. This eliminates the need for separate power outlets near each device, making installation of IP cameras for surveillance systems, wireless access points, and VoIP phones fast and cost-effective. The switch also supports time-based PoE, allowing you to schedule when PoE power is delivered to save energy during off-hours.
Fibre Connectivity for Extended Reach
The two 100/1000 Mbps SFP ports support both multimode and singlemode fibre transceivers, enabling connections over longer distances than standard copper cabling. This makes the DGS-1210-08P ideal for connecting remote buildings, factory floors, or campus networks with high-speed, interference-free fibre links.
Free Management Software
D-Link includes free network management tools to simplify deployment and ongoing administration. The D-Link Network Assistant (DNA) automatically discovers all D-Link switches on your network and allows batch configuration and firmware updates. The D-View 7 Network Management System provides comprehensive monitoring and control with support for up to 25 nodes and 2 probes at no additional cost.
Energy Efficiency and Green Technology
Compliant with IEEE 802.3az Energy Efficient Ethernet, the DGS-1210-08P automatically reduces power consumption during periods of low network activity. Additional green features include automatic power adjustment based on cable length, unused port shutdown, LED shutoff, and system hibernation scheduling - all helping to lower your total cost of ownership while supporting environmental sustainability.
Ideal Applications
-
IP Surveillance Networks: Power and connect IP security cameras with Auto Surveillance VLAN for optimised video streaming
-
VoIP Deployments: Support Voice over IP phones with Auto Voice VLAN and QoS prioritisation
-
Wireless Network Expansion: Power and manage Wi-Fi access points across multiple floors or buildings
-
Small Business Networks: Cost-effective managed switching with enterprise-level features for growing businesses
-
Education and Hospitality: Quiet fanless operation ideal for classrooms, hotels, and open office environments
What's in the Box
- D-Link DGS-1210-08P 8-Port Gigabit Smart Managed PoE Switch
- Power cord
- Rack mount kit
- Quick installation guide
- Warranty card
Full Specifications
Hardware
| Network Ports |
8 x 10/100/1000BASE-T Gigabit Ethernet PoE+ ports
2 x 100/1000 Mbps SFP ports |
| PoE Standard |
IEEE 802.3af (up to 15.4W per port)
IEEE 802.3at (up to 30W per port) |
| Total PoE Budget |
65W |
| Switching Capacity |
20 Gbps |
| Transmission Method |
Store-and-forward |
| MAC Address Table |
8K entries |
| Dimensions (W x D x H) |
280 x 180 x 44 mm (11 x 7.09 x 1.73 inches) |
| Cooling |
Fanless design |
Standards Compliance
| Ethernet Standards |
IEEE 802.3 10BASE-T
IEEE 802.3u 100BASE-TX
IEEE 802.3ab 1000BASE-T
IEEE 802.3x Flow Control |
| PoE Standards |
IEEE 802.3af
IEEE 802.3at |
| Energy Efficiency |
IEEE 802.3az Energy Efficient Ethernet |
Layer 2 Features
| VLANs |
Port-based VLAN, 802.1Q VLAN (up to 256 static groups)
GVRP, Auto Surveillance VLAN, Auto Voice VLAN |
| Quality of Service |
802.1p priority queuing, bandwidth control per port |
| Spanning Tree |
STP, RSTP, MSTP |
| Link Aggregation |
LACP (up to 4 groups, 8 ports per group) |
| Multicast |
IGMP Snooping v1/v2/v3 |
| Port Mirroring |
One-to-one, many-to-one |
Security Features
| Authentication |
802.1X port-based authentication, RADIUS support |
| Access Control |
Access Control Lists (ACLs), Port Security |
| Attack Prevention |
D-Link Safeguard Engine, ARP spoofing prevention
DHCP server screening, DoS attack prevention |
| Network Diagnostics |
Loopback detection, Cable diagnostics |
Management
| Management Interface |
Web-based GUI, SNMP v1/v2c/v3, Telnet, RMON |
| Management Software |
D-Link Network Assistant (DNA)
D-View 7 Network Management System (free license for 25 nodes) |
| Configuration Files |
Dual configuration file support |
Power & Environment
| Input Voltage |
100-240V AC, 50/60Hz |
| Power Consumption |
Maximum: 73.5W (with full PoE load)
Idle: 8.5W (without PoE devices) |
| Operating Temperature |
0°C to 50°C (32°F to 122°F) |
| Storage Temperature |
-40°C to 70°C (-40°F to 158°F) |
| Operating Humidity |
10% to 90% non-condensing |
Warranty
| Warranty Period |
Limited Lifetime Warranty (after product registration) |
Specifications are sourced from the manufacturer product page and may be updated.
