D-Link DGS-1210-10 10-Port Gigabit Smart Managed Switch
The D-Link DGS-1210-10 is a powerful 10-port Gigabit Smart Managed Switch designed for small to medium-sized businesses seeking reliable network performance and advanced management capabilities. With 8 Gigabit Ethernet ports and 2 SFP uplink ports, this fanless switch delivers enterprise-grade Layer 2+ features, comprehensive security, and energy-efficient operation in a compact desktop or rackmount form factor. Perfect for expanding networks with high-speed connectivity, surveillance systems, and VoIP deployments.
Key Features
-
8 x 10/100/1000BASE-T Gigabit Ports: High-speed connectivity for desktops, servers, IP cameras, and access points
-
2 x Gigabit SFP Uplink Ports: Flexible fibre optic connectivity for long-distance connections and high-speed uplinks
-
Advanced Layer 2+ Features: Includes VLAN support, QoS, bandwidth control, static routing, IGMP snooping, port mirroring, link aggregation, and spanning tree protocol for optimized network performance
-
Surveillance Mode with ONVIF Support: Automatically detects and manages compatible IP cameras with dedicated surveillance VLAN and simplified web interface
-
Comprehensive Security: Access Control Lists (ACL), 802.1X/RADIUS authentication, ARP spoofing prevention, and D-Link Safeguard Engine protect against network threats
-
Energy-Efficient & Silent Operation: Fanless design with IEEE 802.3az Energy Efficient Ethernet and D-Link Green 3.0 technology reduces power consumption and noise
-
Flexible Management: Web-based GUI, CLI, SNMP, and support for D-Link Nuclias Connect and D-View network management systems
-
NDAA Compliant: Meets strict regulatory standards for government and enterprise projects
-
Lifetime Warranty: Backed by D-Link's Lifetime Protection after registration
Enterprise-Grade Network Performance
The DGS-1210-10 delivers 20 Gbps switching capacity and 14.88 Mpps forwarding rate, ensuring smooth data transmission across all connected devices. The switch supports an 8,000-entry MAC address table and features advanced traffic management with Quality of Service (QoS) based on 802.1p CoS and DSCP markings. Static routing capabilities allow communication between different VLAN segments, making your network faster and more efficient without burdening your router.
Surveillance & VoIP Optimisation
Ideal for IP surveillance deployments, the switch features a dedicated Surveillance Mode that consolidates data and video transmission through a single device. It automatically detects ONVIF-compliant cameras and places them in a dedicated VLAN with optimized video traffic handling. Auto Voice VLAN technology identifies VoIP traffic and segments it automatically, ensuring high-quality voice calls with priority QoS treatment.
Network Security & Reliability
Protect your business network with robust security features including 802.1X port-based authentication, comprehensive Access Control Lists, and the proprietary D-Link Safeguard Engine that defends against broadcast, multicast, and unicast flooding attacks. Loopback detection automatically identifies and shuts down ports creating switching loops, while cable diagnostics help administrators quickly troubleshoot and resolve network issues.
Energy Savings & Green Technology
The DGS-1210-10 incorporates D-Link Green 3.0 technology and complies with IEEE 802.3az to automatically reduce power consumption during periods of low network activity. The switch detects cable length and adjusts power accordingly, and supports time-based port shutdown schedules and LED shutoff to minimize energy usage during off-hours. The fanless design ensures silent operation, extended lifespan, and maximum power consumption of just 13.7W.
Flexible Deployment Options
Designed for versatile installation, the compact switch can be deployed as a desktop unit or rackmounted in a standard 19-inch rack. Multiple management interfaces including intuitive web UI, command-line interface (CLI), and SNMP provide administrators with flexible control options. Optional integration with D-Link Nuclias Connect enables centralized management of up to 1,500 switches and access points from a single platform.
Universal Connectivity
-
8 x 10/100/1000BASE-T RJ-45 ports: Auto-sensing Gigabit Ethernet with auto-MDI/MDIX support
-
2 x 100/1000 Mbps SFP ports: For fibre optic connections using multimode or singlemode SFP transceivers
-
Console port: For direct CLI management access
What's in the Box
- D-Link DGS-1210-10 Smart Managed Switch
- Power adapter
- Power cord
- Rubber feet
- Rackmount kit
- Quick installation guide
- Warranty card
Full Specifications
Hardware
| Ports |
8 x 10/100/1000BASE-T, 2 x 100/1000 Mbps SFP |
| Switching Capacity |
20 Gbps |
| Forwarding Rate |
14.88 Mpps |
| MAC Address Table |
8,000 entries |
| Packet Buffer |
4.1 Mbits |
| Flash Memory |
32 MB |
| Form Factor |
Desktop/Rackmount |
Network Features
| VLAN Support |
802.1Q VLAN with up to 256 static VLAN groups |
| QoS |
802.1p CoS, DSCP, bandwidth control |
| IGMP Snooping |
IGMP v1/v2/v3 |
| Link Aggregation |
IEEE 802.3ad LACP |
| Spanning Tree Protocol |
STP, RSTP, MSTP |
| Static Routing |
IPv4 static routes |
| Surveillance Mode |
Auto Surveillance VLAN with ONVIF support |
| Voice VLAN |
Auto Voice VLAN |
Security
| Authentication |
802.1X port-based, RADIUS |
| Access Control |
Access Control Lists (ACL) |
| Protection Features |
ARP spoofing prevention, D-Link Safeguard Engine, DHCP server screening |
| Port Security |
MAC address binding, port isolation |
| Storm Control |
Broadcast, multicast, unicast |
Management
| Management Interface |
Web-based GUI, CLI (Telnet/SSH), SNMP v1/v2c/v3 |
| Management Software |
D-Link Network Assistant (DNA), D-View 7, Nuclias Connect (optional) |
| Diagnostics |
Cable diagnostics, loopback detection |
| IPv6 Support |
IPv6 management ready |
Power & Environment
| Power Input |
100-240V AC, 50/60 Hz |
| Power Consumption |
Maximum: 13.7W (100V) / 13.9W (240V) |
| Heat Dissipation |
118.92 BTU/hr (100V) / 116.7 BTU/hr (240V) |
| Acoustics |
0 dB(A) (fanless) |
| Operating Temperature |
-5°C to 50°C (23°F to 122°F) |
| Storage Temperature |
-20°C to 70°C (-4°F to 158°F) |
| Operating Humidity |
0% to 95% (non-condensing) |
| Storage Humidity |
0% to 95% (non-condensing) |
Physical
| Dimensions (L x W x H) |
280 x 180 x 44 mm (11.02 x 7.09 x 1.73 inches) |
| Weight |
1.75 kg (3.86 lbs) |
| Certifications |
CE Class A, FCC Class A, VCCI Class A, BSMI, NDAA Compliant |
| MTBF |
729,258 hours |
Standards Compliance
| IEEE Standards |
802.3 10BASE-T, 802.3u 100BASE-TX, 802.3ab 1000BASE-T, 802.3z 1000BASE-SX/LX, 802.3x flow control, 802.3ad LACP, 802.3az EEE, 802.1D STP, 802.1w RSTP, 802.1s MSTP, 802.1Q VLAN, 802.1p QoS, 802.1X authentication |
| RoHS Compliant |
Yes |
Warranty
| Warranty Period |
Lifetime (after product registration) |
Specifications are sourced from the manufacturer product page and may be updated.
