D-Link DGS-1510-28X 28-Port Stackable Gigabit Smart Managed Switch with 10G SFP+ Uplinks
The D-Link DGS-1510-28X is a stackable smart managed switch designed for small and medium-sized enterprises requiring Layer 3 management, scalable 10G connectivity, and advanced stacking capabilities. Equipped with 24 Gigabit Ethernet ports and 4 x 10G SFP+ uplink ports, this switch supports computers, servers, IP cameras, wireless access points, network storage devices, and VoIP phones with professional-grade reliability.
Why Choose the DGS-1510-28X?
-
Physical Stacking: Create a stack of up to 6 units for a total of 288 Gigabit ports in a fault-tolerant ring or linear topology
-
10G SFP+ Uplinks: 4 high-speed fibre ports for stacking or uplinks to core networks and servers
-
Layer 3 Capabilities: Static routing, IPv4/IPv6 support, MSTP, and ERPS for advanced network segmentation
-
Surveillance Mode with ONVIF: Streamlines IP camera deployment and management with automatic device detection
-
Energy Efficient: D-Link Green technology saves up to 73% energy with smart fan control and efficient silicon
-
Comprehensive Security: IGMP snooping, ACLs, port security, ARP spoofing prevention, and D-Link Safeguard Engine
High-Speed Connectivity
The DGS-1510-28X delivers 24 x 10/100/1000BASE-T ports for seamless connection to endpoint devices, plus 4 x 10G SFP+ ports for high-bandwidth uplinks or physical stacking. Depending on topology, use one or two SFP+ ports to stack multiple switches using Direct Attach Cables or compatible SFP+ transceivers, with remaining ports available for core network or server connectivity.
Advanced Management & Security
Built for IT professionals, the DGS-1510-28X offers Industry Standard CLI, web-based UI, and serial console access for complete control over VLANs, link aggregation (LACP), static routing, multiple firmware images, and configuration files. Virtual stacking via D-Link's Single IP Management (SIM) simplifies management of up to 32 units from a single interface.
Ideal for Business Networks
Whether you're building out office infrastructure, deploying IP surveillance systems, or connecting wireless access points across multiple floors, the DGS-1510-28X provides the performance, scalability, and reliability your network demands. Its fanless design (for select models) or smart fan ensures quiet operation in professional environments.
Universal Connectivity
- 24 x 10/100/1000BASE-T Gigabit Ethernet ports
- 4 x 10G SFP+ ports (for stacking or uplinks)
- 1 x Console port (RJ-45)
What's in the Box
- D-Link DGS-1510-28X Switch
- Power cord
- Rack mounting kit
- Console cable
- Quick Installation Guide
Full Specifications
Hardware
| Ports |
24 x 10/100/1000BASE-T, 4 x 10G SFP+, 1 x Console (RJ-45) |
| Stacking |
Up to 6 units (physical), up to 32 units (virtual via SIM) |
| Form Factor |
19-inch rackmountable 1U |
Performance
| Switching Capacity |
128 Gbps |
| Forwarding Rate |
95.24 Mpps |
| MAC Address Table |
16,000 entries |
Layer 2 Features
| VLANs |
4096 VLANs, 802.1Q tagging |
| Spanning Tree |
STP, RSTP, MSTP |
| Link Aggregation |
LACP (IEEE 802.3ad) |
| IGMP Snooping |
v1, v2, v3 |
| Port Mirroring |
Many-to-one |
Layer 3 Features
| Static Routing |
IPv4/IPv6 |
| ERPS |
Ethernet Ring Protection Switching (G.8032) |
Security
| Authentication |
802.1X, RADIUS, TACACS+ |
| Access Control |
ACL (MAC, IP, IPv6), Port security |
| Protection |
ARP Spoofing Prevention, DoS attack prevention, D-Link Safeguard Engine |
Management
| Interfaces |
Web UI, CLI (Telnet/SSH), Console, SNMP v1/v2c/v3 |
| D-Link Tools |
D-View 7, D-Link Network Assistant, Single IP Management (SIM) |
| Firmware |
Dual firmware image support |
Power & Environment
| Power Input |
100-240V AC, 50/60Hz |
| Maximum Power Consumption |
30W |
| Operating Temperature |
0°C to 50°C |
| Cooling |
Smart fan (temperature-controlled) |
Physical
| Dimensions (W × D × H) |
440 × 280 × 44 mm |
| Mounting |
19-inch rack, 1U |
| Warranty |
Lifetime |
Specifications are sourced from the manufacturer product page and may be updated.
