D-Link DGS-3130-54TS 54-Port Layer 3 Stackable Managed Gigabit Switch
The D-Link DGS-3130-54TS is a high-performance Lite Layer 3 Stackable Managed Switch designed for secure enterprise and metro Ethernet access networks. With 48 Gigabit Ethernet ports, 2 × 10GBASE-T ports, and 4 × 10G SFP+ uplink ports, this switch delivers exceptional connectivity and bandwidth for demanding business environments including data centres, corporate networks, and IP surveillance systems.
Key Features
-
54 Total Ports: 48 × 10/100/1000BASE-T Gigabit Ethernet ports plus 6 high-speed 10 Gigabit uplink ports for maximum flexibility
-
Layer 3 Routing: Advanced routing protocols including RIP/RIPng and OSPFv2/v3 for intelligent traffic management
-
Stackable Design: Stack up to 9 units with 80 Gbps stacking bandwidth for seamless network expansion
-
Enterprise-Grade Reliability: Dual power input support, G.8032 ERPS with 50ms recovery time, and 6kV surge protection on all ports
-
Advanced Security: 802.1X authentication, ACLs, DHCP Snooping, IP-MAC-Port Binding, and DoS attack prevention
-
QoS Optimisation: Multi-layer Quality of Service features prioritise VoIP, video conferencing, IPTV, and IP surveillance traffic
High-Performance Switching
The DGS-3130-54TS delivers 216 Gbps switching capacity with a forwarding rate of 161 Mpps, ensuring smooth data transfer even under heavy network loads. The 4 MB packet buffer minimises packet loss during traffic bursts, making it ideal for bandwidth-intensive applications.
Flexible 10 Gigabit Connectivity
Six dedicated 10 Gigabit uplink ports provide versatile options for high-speed connections to core networks and server farms. The combination of 2 × 10GBASE-T copper ports and 4 × 10G SFP+ fibre ports allows you to choose the best connectivity option for your infrastructure, whether copper or fibre-based.
Powerful Layer 3 Features
Go beyond basic switching with integrated Layer 3 routing capabilities. Support for static routing, RIP, RIPng, and OSPF v2/v3 enables the switch to route traffic between VLANs efficiently, optimising network performance and reducing unnecessary data transfer to your core routers.
Physical Stacking for Maximum Scalability
Physical stacking allows you to connect up to 9 switches that operate as a single logical unit, providing up to 324 Gigabit ports with simplified management. With 80 Gbps stacking bandwidth per device, the stack ensures high-speed interconnectivity between switches for smooth performance across your entire network.
Enterprise-Grade Network Reliability
Designed for mission-critical environments, the DGS-3130-54TS features comprehensive redundancy and protection mechanisms:
-
Redundant Power Supply Support: Optional DPS-500A external redundant power supply ensures continued operation during power failures
-
G.8032 ERPS: Ethernet Ring Protection Switching with sub-50ms recovery time minimises network downtime
-
6kV Surge Protection: Built-in surge protection on all Gigabit Ethernet and 10GBASE-T ports protects against electrical surges
-
Spanning Tree Protocols: 802.1D/w/s STP, RSTP, and MSTP prevent network loops and enhance resilience
-
Link Aggregation: 802.3ad LACP for load sharing and redundancy in switch cascading configurations
Comprehensive Security Features
Protect your network from unauthorised access and threats with advanced security capabilities including 802.1X port-based authentication with RADIUS and TACACS+ support, Web-based Access Control (WAC), and MAC-based Access Control. Additional features like IP-MAC-Port Binding (IMPB), DHCP Snooping, Dynamic ARP Inspection, and DoS attack prevention provide multiple layers of network protection. The switch also supports Microsoft NAP (Network Access Protection) for policy enforcement.
Intelligent Traffic Management
Ensure critical applications always receive the bandwidth they need with multi-layer QoS/CoS features. Traffic Shaping guarantees bandwidth for priority services like VoIP and video conferencing. L2 Multicast support with IGMP/MLD Snooping efficiently handles IPTV and multicast applications, while ISM VLAN sends multicast streams in dedicated VLANs to save bandwidth and enhance backbone security.
Flexible Management Options
Manage your network your way with multiple management interfaces including an intuitive multilingual web-based GUI, industry-standard CLI, SNMP, and optional D-View Network Management Software for centralised control. The integrated USB 2.0 port allows you to boot images and upload configuration files directly from USB storage, and conveniently save syslog files for easy backup and recovery.
Ideal Applications
- Enterprise and campus network access layer deployment
- Metro Ethernet service provider networks
- Data centre and server farm connectivity
- IP surveillance and security camera networks
- VoIP and unified communications infrastructure
- IPTV and digital signage networks
- High-density network aggregation
What's in the Box
- D-Link DGS-3130-54TS Managed Switch
- Power cord
- Console cable
- Rack mount kit
- Quick installation guide
Full Specifications
Hardware
| Total Ports |
54 ports |
| Gigabit Ethernet Ports |
48 × 10/100/1000BASE-T RJ-45 ports |
| 10GBASE-T Ports |
2 × 10GBASE-T copper ports |
| 10G SFP+ Ports |
4 × 10G SFP+ fibre ports |
| Stacking Ports |
4 × 10G ports (SFP+) for stacking |
| USB Port |
1 × USB 2.0 Type A port |
Performance
| Switching Capacity |
216 Gbps |
| Packet Forwarding Rate |
161 Mpps (64-byte packets) |
| Packet Buffer Memory |
4 MB |
| Stacking Bandwidth |
80 Gbps per unit |
| Maximum Stack Units |
Up to 9 units (6 for 54-port models) |
| Maximum Ports per Stack |
324 Gigabit ports |
Layer 2 Features
| VLAN |
4K VLAN groups, Port-based VLAN, 802.1Q tag VLAN |
| Spanning Tree |
802.1D STP, 802.1w RSTP, 802.1s MSTP |
| Link Aggregation |
802.3ad LACP |
| Multicast |
IGMP v1/v2/v3 Snooping, MLD v1/v2 Snooping |
| Ring Protection |
G.8032 ERPS with sub-50ms recovery |
| Loopback Detection |
Yes |
Layer 3 Features
| Routing Protocols |
Static routing, RIP v1/v2, RIPng, OSPF v2/v3 |
| IP Interfaces |
Up to 128 IP interfaces |
| VRRP |
Virtual Router Redundancy Protocol support |
| IPv6 |
IPv6 Neighbor Discovery Protocol (ND), ARP Proxy |
Security
| Authentication |
802.1X, RADIUS, TACACS+, Web-based Access Control, MAC-based Access Control |
| Access Control Lists |
Multi-layer and packet content ACLs |
| Port Security |
IP-MAC-Port Binding (IMPB), DHCP Snooping |
| Attack Prevention |
DoS attack prevention, Dynamic ARP Inspection, IP Source Guard |
| Storm Control |
Broadcast, multicast, and unicast storm control |
| Microsoft NAP |
Network Access Protection support |
| Surge Protection |
6 kV surge protection on all GE and 10GBASE-T ports |
Quality of Service
| QoS Features |
802.1p priority queues, DSCP, ToS |
| Traffic Shaping |
Per-port traffic shaping and bandwidth control |
| Queue Scheduling |
Strict priority, weighted round-robin |
Management
| Management Interfaces |
Web-based GUI (multilingual), CLI, SNMP v1/v2c/v3, Telnet, SSH |
| Network Management |
D-View Network Management Software (optional), D-Link Network Assistant |
| Configuration |
Multiple configuration files, multiple firmware images |
| Monitoring |
RMON, Port mirroring, sFlow, Cable diagnostics |
| Logging |
Syslog, SMTP email alerts |
Power
| Input Voltage |
100-240 VAC, 50/60 Hz |
| Power Consumption |
50.6 W maximum (172.72 BTU/h) |
| Redundant Power Supply |
Optional DPS-500A external redundant power supply |
Environmental
| Operating Temperature |
0°C to 50°C (32°F to 122°F) |
| Storage Temperature |
-40°C to 70°C (-40°F to 158°F) |
| Operating Humidity |
10% to 90% non-condensing |
| Acoustic Noise |
Maximum: 51.9 dB / Minimum: 32.7 dB |
| MTBF |
478,258 hours |
Physical Specifications
| Dimensions (W × D × H) |
440 × 290 × 44 mm (17.3 × 11.4 × 1.7 inches) |
| Weight |
3.72 kg (8.2 lbs) |
| Form Factor |
1U 19-inch rack-mountable |
Standards & Certifications
| IEEE Standards |
802.3 10BASE-T, 802.3u 100BASE-TX, 802.3ab 1000BASE-T, 802.3an 10GBASE-T, 802.3ae 10G SFP+, 802.3x flow control, 802.3ad LACP, 802.1D/w/s STP/RSTP/MSTP, 802.1Q VLAN, 802.1p priority, 802.1X authentication, 802.1ab LLDP |
| Safety |
CE, FCC, C-Tick, VCCI |
Warranty
| Warranty Period |
Limited Lifetime Warranty with Next Business Day replacement |
Specifications are sourced from the manufacturer product page and may be updated.
