D-Link DIS-100G-5W Industrial 5-Port Gigabit Ethernet Switch
The D-Link DIS-100G-5W is a rugged, industrial-grade unmanaged Gigabit switch engineered to deliver reliable network connectivity in the harshest environments. With 5 x 10/100/1000BASE-T ports, this plug-and-play switch is ideal for surveillance systems, factory automation, smart city infrastructure, and outdoor wireless networks. Built to withstand extreme temperatures from -40°C to +75°C, the DIS-100G-5W ensures your network stays online in industrial cabinets, outdoor enclosures, and demanding manufacturing environments where commercial switches simply can't survive.
Why Choose the DIS-100G-5W?
-
Extreme Environment Reliability: Operates in temperatures from -40°C to +75°C with cold start capability
-
Industrial-Grade Construction: IP30-rated metal housing protects against dust, vibration, shock, and electromagnetic interference
-
5 Gigabit Ethernet Ports: Full wire-speed 10/100/1000Mbps auto-negotiating ports for high-speed data transfer
-
Plug-and-Play Simplicity: Unmanaged switch requires zero configuration for instant deployment
-
Redundant Power Input: Dual 12-58V DC power terminals ensure continuous operation if one supply fails
-
Flexible Mounting: DIN-rail clip and wall-mount options for cabinet or enclosure installation
-
Fanless Design: Silent operation with optimised passive cooling extends product life
-
Certified Durability: NEMA-TS2, EN50121-4, vibration, shock, and free-fall certified
Built for Industrial Applications
Unlike standard office switches, the DIS-100G-5W is purpose-built for industrial deployments. The IP30-rated solid metal housing shields internal components from dust, moisture, and physical damage, while high electromagnetic compatibility (EMC) protects against interference from motors, generators, and other industrial equipment. Whether you're installing IP surveillance cameras in outdoor cabinets, connecting industrial controllers on a factory floor, or building a smart traffic management system, this switch delivers the reliability and durability you need.
Quality of Service & Green Ethernet
The DIS-100G-5W features IEEE 802.1p Quality of Service (QoS) with 4 hardware queues per port, ensuring that time-sensitive traffic like video surveillance and SCADA data gets priority even during network congestion. Green Ethernet technology including IEEE 802.3az Energy-Efficient Ethernet (EEE) reduces power consumption during low utilization, while link status detection powers down unused ports and cable length detection optimizes power based on cable distance.
Simple Installation, Zero Configuration
Installation is effortless thanks to the included snap-to-DIN-rail clip and wall-mounting hardware. The compact form factor fits easily in crowded enclosures, and the Auto-MDI/MDIX feature on all ports means you can use straight-through or crossover cables without worry. LED indicators on the front panel display link, activity, and speed status at a glance. With plug-and-play operation, your network is up and running in minutes without software or configuration.
Perfect for Australian Industrial & Surveillance Projects
Ideal for outdoor surveillance installations, mining operations, factory automation, transport infrastructure, water treatment facilities, and any application requiring network connectivity in extreme or remote locations across Australia. Combine with D-Link industrial SFP transceivers for fiber connectivity over long distances.
What's in the Box
- DIS-100G-5W Industrial Gigabit Switch
- DIN-rail mounting clip
- Wall-mounting kit
- Quick installation guide
Full Specifications
Ports & Connectivity
| Number of Ports |
5 x 10/100/1000BASE-T RJ-45 ports |
| Port Functions |
IEEE 802.3 Ethernet, IEEE 802.3u Fast Ethernet, IEEE 802.3ab Gigabit Ethernet, IEEE 802.3x Flow Control, IEEE 802.3az Energy-Efficient Ethernet |
| Media Interface |
Auto-MDI/MDIX on all twisted pair ports |
Performance
| Switching Capacity |
10 Gbps |
| Forwarding Rate |
7.44 Mpps (wire-speed) |
| MAC Address Table |
8,192 entries |
| Transmission Method |
Store-and-forward |
| Jumbo Frame |
Up to 9.6 KB |
Advanced Features
| Quality of Service |
IEEE 802.1p QoS with 4 hardware queues per port |
| Storm Control |
Broadcast/Multicast/Unicast storm control |
| Green Technology |
IEEE 802.3az EEE, link status detection, cable length detection |
Power
| Power Input |
12 to 58V DC dual terminal block input (redundant) |
| Power Consumption |
Maximum 3.57W |
Physical & Environmental
| Dimensions (H x W x D) |
89 x 112.2 x 29.1 mm (3.5" x 4.4" x 1.1") |
| Weight |
295 g (10.41 oz) |
| Housing |
IP30-rated solid metal enclosure |
| Operating Temperature |
-40°C to +75°C with cold start capability |
| Storage Temperature |
-40°C to +85°C |
| Operating Humidity |
10% to 95% non-condensing |
| Cooling |
Fanless, passive cooling design |
| Mounting Options |
Desktop, DIN-rail (clip included), wall-mount |
Certifications & Compliance
| Safety |
UL60950-1, CE |
| EMC |
FCC Part 15 Class A, ICES-003, CE (EN 55022/55024) |
| Industrial Standards |
NEMA-TS2, EN50121-4 wayside control |
| Environmental Tests |
IEC 60068-2-27 shock, IEC 60068-2-32 free-fall, IEC 60068-2-6 vibration |
| ESD/Surge Protection |
EN 61000-4-2 ESD Level 3, EN 61000-4-5 Surge Level 3 |
Warranty
| Warranty Period |
5-year D-Link warranty (Lifetime Limited Warranty in USA) |
Specifications are sourced from the manufacturer product page and may be updated.
