D-Link DPS-700 589W Redundant Power Supply for PoE Managed Switches
The D-Link DPS-700 is a professional-grade 589-watt redundant power supply unit (RPS) designed specifically for D-Link's Power over Ethernet (PoE) managed switches. Engineered for business-critical networks, this rack-mountable RPS provides seamless failover protection and additional PoE power budget expansion, ensuring your network stays online even in the event of a primary power supply failure.
Uninterrupted Network Uptime
Network downtime can be costly for businesses. The DPS-700 continuously monitors your switch's internal power supply with an integrated detection circuit. In the event of a power interruption, the redundant power supply is immediately triggered, keeping your LAN switch and connected devices operational without interruption. This low-cost, simple solution prevents the shutdown of critical switching devices, attached endpoints, or entire network segments.
Key Features
-
589W output power: Full power backup for demanding PoE switches
-
1+1 power budget support: Doubles the PoE budget on compatible switches, providing an additional 370W of PoE power to support more powered devices
-
19-inch rack-mountable design: 1U height standard rack mount for easy installation alongside your network equipment
-
Hot-swappable capability: Replace or service without network disruption
-
LED status indicators: Visual monitoring of power supply status at a glance
-
Solid metal housing: Durable construction for reliable long-term operation
-
High reliability: 624,961 hours MTBF (Mean Time Between Failures)
Broad Switch Compatibility
The DPS-700 is compatible with a wide range of D-Link managed PoE switches, including the DGS-1500, DGS-1510, DGS-1520, DGS-3120, DGS-3130, DGS-3420, DGS-3620, DGS-3630, and DWS-3160 series. This makes it an ideal redundant power solution for enterprise networks, data centres, schools, hotels, and other environments where network reliability is paramount.
Enhanced PoE Power Budget
Beyond redundancy, the DPS-700 supports PoE power load sharing. When cascaded with a device's internal power supply, the power system can provide an additional PoE power budget to the switch, enabling you to connect and power more PoE devices such as IP cameras, wireless access points, VoIP phones, and other network equipment without worrying about power limitations.
What's in the Box
- DPS-700 Redundant Power Supply Unit
- 1-meter DC power cable
- Rack mount brackets
- Quick Installation Guide
Full Specifications
Power
| Output Power |
589 Watts |
| Input Voltage Range |
90 to 264 VAC |
| Input Frequency |
47 to 63 Hz |
| Additional PoE Budget |
370W |
| MTBF |
624,961 hours |
Physical
| Dimensions (W × D × H) |
441 × 199 × 44 mm (17.36 × 7.83 × 1.73 in.) |
| Form Factor |
19-inch rack-mount width, 1U height |
| Weight |
4.46 kg (9.83 lbs) |
| Housing |
Solid metal case |
Features
| Monitoring |
Integrated detection circuit for continuous power supply monitoring |
| LED Indicators |
Status LEDs for power and fault indication |
| Hot-swappable |
Yes |
| 1+1 Power Capability |
Yes (doubles PoE budget on supported switches) |
Compatibility
| Compatible Switches |
DGS-1500-28P, DGS-1510 Series, DGS-1520 Series, DGS-3120-24PC, DGS-3120-48PC, DGS-3130 Series, DGS-3420-28PC, DGS-3420-52P, DGS-3620-28PC, DGS-3620-52P, DGS-3630 Series, DWS-3160-24PC |
Environmental & Warranty
| Warranty |
2 Years (see package for details) |
Specifications are sourced from the manufacturer product page and may be updated.
