D-Link DSL-226 Wireless N300 VDSL2/ADSL2+ Modem Router NBN Ready
The D-Link DSL-226 Wireless N300 VDSL2/ADSL2+ Modem Router is everything you need for reliable, high-speed Internet access throughout your entire home or office. Designed for multi-WAN connectivity, this versatile router combines a VDSL2/ADSL2+ modem and high-end wireless router in one compact device, delivering premium performance for streaming, downloading, browsing, and gaming. With NBN/UFB compatibility, the DSL-226 is ready for all connection types in Australia and New Zealand, including FTTN, FTTP, HFC, and traditional ADSL services.
Why You'll Love the D-Link DSL-226
-
Wireless N300 speeds up to 300 Mbps: Stream HD content and browse the web with speeds up to 4 times faster than 802.11g
-
Universal DSL connectivity with VLAN tagging: Built-in VDSL2/ADSL2+ modem connects to your high-speed broadband service
-
NBN/UFB ready for all Australian connections: Compatible with FTTN, FTTP, HFC, Fixed Wireless, and ADSL2+ services
-
Four Fast Ethernet LAN ports plus configurable WAN/LAN port: Connect multiple wired devices at speeds up to 100 Mbps
-
SuperSpeed USB 3.0 port: Share media from a storage device across your network or connect a 4G LTE adapter for backup connectivity
-
Easy setup with WPS button: Connect wireless devices securely with the touch of a button
Fast, Reliable Wireless Connectivity
The DSL-226 harnesses Wireless N technology to deliver data throughput rates up to 300 Mbps on the 2.4 GHz band. Whether you're streaming video, gaming online, browsing the web, or video calling, you'll enjoy smooth, lag-free performance. The router is backward compatible with 802.11b and 802.11g devices, ensuring your older tech stays connected while you enjoy enhanced reception across the board.
Flexible Connection Options for Every Setup
With multiple WAN connection options, the DSL-226 accommodates different broadband scenarios. Connect via VDSL2 or ADSL2+ using the built-in DSL modem with download speeds up to 24 Mbps on ADSL2+ or up to 100 Mbps on VDSL2. Alternatively, use the configurable Ethernet WAN/LAN port to connect to an NBN connection box, cable modem, or fibre service. The router supports SOS/ROC requirements for Australian NBN services and includes VLAN tagging for ISP compatibility.
Wired and Wireless, All in One
In addition to blazing wireless speeds, the DSL-226 features four Fast Ethernet LAN ports for connecting desktop computers, gaming consoles, smart TVs, and network storage devices at speeds up to 100 Mbps. One port is configurable as either LAN or WAN, giving you maximum flexibility for your home or small office network.
Enhanced Security and Network Management
Rest easy knowing your network is protected. The DSL-226 includes WPA/WPA2 and WEP wireless encryption, Stateful Packet Inspection (SPI) firewall, and hacker attack logging to defend against unauthorized access and threats including SYN/RST attacks, Ping attacks, and FIN/PSH attacks. Quality of Service (QoS) with priority queues ensures smooth network performance for all users, even during heavy traffic. Additional features include content filtering by URL or domain name, IP/MAC address filtering, and scheduled wireless access for parental controls.
USB 3.0 for Media Sharing and 4G Backup
The integrated SuperSpeed USB 3.0 port lets you connect a USB storage device to share photos, videos, music, and files across your local network. You can also connect a compatible D-Link 4G LTE USB adapter (DWM-222) to provide cellular broadband access or failover connectivity when your primary connection is unavailable.
Easy Setup and Management
Setting up the DSL-226 is simple with the D-Link Setup Wizard. Just open your browser, follow the step-by-step prompts, and you'll be online in minutes. The WPS button provides an easy way to establish secure wireless connections with compatible devices. Remote management capabilities allow service providers to provision the router remotely, reducing deployment time for ISPs and businesses.
Universal Connectivity
-
1 × DSL port: Connects to VDSL2/ADSL2+ telephone line
-
4 × Fast Ethernet LAN ports (10/100 Mbps): Ports 2-4 for wired devices
-
1 × Configurable Ethernet WAN/LAN port (10/100 Mbps): Port 1 configurable for cable/NBN/UFB modem or wired device
-
1 × USB 3.0 port: For storage sharing or 4G LTE adapter
- Wi-Fi Protected Setup (WPS) button
- Power on/off switch
- Reset button
What's in the Box
- D-Link DSL-226 Wireless N300 VDSL2/ADSL2+ Modem Router
- Power adapter
- Ethernet cable
- DSL cable (telephone cable)
- Quick Install Guide
- Wi-Fi Configuration Card
Full Specifications
| Model |
DSL-226 |
| Wireless Standard |
IEEE 802.11n/g/b |
| Wireless Speed |
Up to 300 Mbps (N300) |
| Wireless Frequency |
2.4 GHz (Single-band) |
| DSL Standard |
VDSL2, ADSL2+, ADSL |
| ADSL Download Speed |
Up to 24 Mbps downstream, 1 Mbps upstream |
| VDSL Download Speed |
Up to 100 Mbps (profile dependent) |
| Ethernet Ports |
4 × Fast Ethernet (10/100 Mbps), 1 configurable as WAN/LAN |
| USB Ports |
1 × USB 3.0 |
| DSL Port |
1 × RJ-11 |
| Antennas |
2 × external fixed antennas |
| Security |
WPA/WPA2, WEP, SPI Firewall, NAT, DoS attack prevention |
| Quality of Service |
Yes, with priority queues |
| VPN Support |
PPTP, L2TP, IPSec passthrough |
| VLAN Tagging |
802.1p/802.1q support |
| NBN/UFB Compatibility |
All NBN (Australia) and UFB (New Zealand) connection types |
| Dimensions (W × D × H) |
141.2 × 100.1 × 35 mm |
| Weight |
150 g |
| Operating Temperature |
0°C to 40°C |
| Power Supply |
External power adapter (included) |
| Certifications |
CE, RoHS |
| Warranty |
1 Year Limited Warranty |
Specifications are sourced from the manufacturer product page and may be updated.
