D-Link DSS-100E-6P 6-Port Unmanaged PoE Surveillance Switch
The D-Link DSS-100E-6P 6-Port Unmanaged PoE Surveillance Switch is the perfect plug-and-play networking solution for IP camera installations and small surveillance systems. With 4 PoE Fast Ethernet ports and 2 uplink ports, this switch delivers both data and power over a single cable, simplifying installation and reducing cable clutter. Featuring a 55W PoE power budget and extended 250m PoE range, it's designed to power cameras and devices in locations far from power outlets.
Key Features
-
Extended PoE Range: Power devices up to 250 meters away, ideal for long-distance surveillance deployments
-
55W PoE Power Budget: Total power budget across 4 PoE ports to support multiple IP cameras and PoE devices
-
Plug-and-Play Setup: No configuration required - simply connect and start using your network immediately
-
6kV Surge Protection: Built-in surge protection prevents damage from lightning strikes and power surges
-
Energy Efficient: IEEE 802.3az Energy Efficient Ethernet reduces power consumption during low traffic periods
-
Compact Design: Desktop form factor fits easily in tight spaces and cable management enclosures
Perfect for Surveillance Systems
The DSS-100E-6P is purpose-built for surveillance and security camera installations. Its extended PoE range of 250m allows you to position IP cameras virtually anywhere without worrying about proximity to power outlets. The switch intelligently manages power delivery to connected devices and supports both IEEE 802.3af and IEEE 802.3at PoE standards. With 2 dedicated uplink ports, you can easily connect to your Network Video Recorder (NVR) or core network switch for smooth footage transmission.
Plug-and-Play Simplicity
Designed for ease of use, the DSS-100E-6P requires zero configuration. Auto MDI/MDIX support on all ports eliminates the need for crossover cables, and the switch automatically detects connected devices to optimize performance. Whether you're adding IP cameras, IP phones, wireless access points, or other PoE devices, setup is instant. The switch is also highly compatible with a wide variety of IP camera brands, ensuring seamless integration into your surveillance network.
Connectivity & Ports
- 4 × 10/100 Mbps PoE Ethernet ports (IEEE 802.3af/at compliant)
- 2 × 10/100 Mbps Uplink ports (non-PoE)
- Auto MDI/MDIX crossover support on all ports
- Store-and-forward switching method
Reliable & Protected
Built for demanding environments, the DSS-100E-6P includes 6kV surge protection on all ports to safeguard your equipment from electrical damage caused by lightning and power surges. Energy Efficient Ethernet (EEE) technology automatically reduces power usage when network traffic is low, lowering operating costs and extending the life of your switch.
What's in the Box
- DSS-100E-6P 6-Port PoE Surveillance Switch
- Power adapter
- Power cord
- Quick Installation Guide
Full Specifications
Hardware
| Total Ports |
6 |
| PoE Ports |
4 × 10/100 Mbps (Ports 1-4) |
| Uplink Ports |
2 × 10/100 Mbps (Ports 5-6) |
| PoE Standards |
IEEE 802.3af, IEEE 802.3at |
| PoE Power Budget |
55W total |
| Extended PoE Range |
Up to 250 meters at 10 Mbps |
Performance
| Switching Method |
Store-and-forward |
| Data Transfer Rates |
10/100 Mbps per port |
| Auto MDI/MDIX |
Yes, all ports |
Protection & Efficiency
| Surge Protection |
6kV |
| Energy Efficient Ethernet |
IEEE 802.3az |
Physical
| Form Factor |
Desktop, unmanaged |
| Installation |
Plug-and-play (no configuration required) |
Specifications are sourced from the manufacturer product page and may be updated.
