Description
Designed for today’s BYOD classroom, the Epson EB-600 series takes classroom collaboration further. Offering 3x Higher Colour Brightness1 than competitive models, Epson® 3LCD projectors and displays ensure bright, vivid images. It features optional wireless functionality (module sold separately) and advanced connectivity, so teachers can easily share content from multiple student devices, including Chromebooks — up to four at once with Moderator software2. Plus, its lamp lasts up to 10,000 hours in ECO Mode.
KEY FEATURES
- 3 x Brighter Colours and reliable performance – 3LCD, 3-Chip Technology. Look for both high colour brightness and high white brightness
- Bright Images – 3,500 lumens colour/white brightness
- Amazing images – WXGA resolution (1280 x 800) and 16:10 format
- Ultra-short throw presentation display – get a 100" image from as little as 28cm away with virtually no shadow interference
- Simultaneously display and control multiple device screens – wirelessly share content from up to four devices, including Chromebooks, with Moderator software
Manage your display and send announcements remotely – easy network connectivity; software included
- Versatile connectivity – 3x HDMI® supports multiple high-definition A/V devices, with MHL® support
- Powerful sound to engage every student – built-in 16 W speaker and microphone input; or, use external speakers, even in Standby Mode
- 10,000Hr maintenance cycle – the lamp and filter lasts up to 10,000 hours in ECO Mode
BASIC FUNCTIONS
3LCD Technology
All Epson projectors are based on 3-chip LCD technology for amazing colour, incredible detail and solid reliability. 3LCD's 3-chip architecture dedicates an entire chip to process each primary colour – red, green and blue, continuously. Unlike single-chip technology that delivers colour sequentially, you get full-time colour. The result is vibrant, realistic images and video all delivered with 3LCD’s true-to-life colour.
3x Brighter Colours with Epson*
Up to 3x Brighter with Epson Projectors*
Epson projectors use 3LCD Engines that have no colour wheel with a white segment and therefore don't force a tradeoff between white and colour brightness.
In fact, Epson projectors have up to 3x Brighter Colours than their leading competitive 1-chip DLP projectors*. If you are looking for business and education projectors or 720p home entertainment projectors, know that choosing Epson projectors means up to 3x brighter colours. If you are looking for 1080p home entertainment projectors, you consistently get 2x and up to 3x Brighter Colours than competitor 1-chip DLP projectors*.
All Epson projectors list both White Brightness and Colour Brightness specifications, and all have high Colour Brightness.
* Compared to leading 1-chip DLP business and education projectors based on NPD data, July 2011 through June 2012. Colour brightness (colour light output) measured in accordance with IDMS 15.4. Colour brightness will vary depending on usage conditions.
Brighter Images
With brightness up to 3,500 lumens, the screen is easily viewed from anywhere in the classroom, even without dimming the lights.
Readability from Anywhere in the room
Ensure every student in the classroom can easily read and understand the information you're sharing. Offering clear, easy-to-see images up to 100", Epson displays help students learn and retain information, regardless of where they sit.
Wide viewing angle
Clear images can be seen from any angle with no limitations of reflective glare. Projected images also allow you to get closer to the image without straining your eyes.
High Resolution
Featuring native resolution of WXGA (1280 x 800), the Epson EB-600 series delivers high quality images and crisp, sharp text without any distortion.
INTERACTIVE LESSONS
Finger-touch and Dual Pen
Use your fingers to annotate directly onto the screen. Epson's interactive pens are now even more responsive and easy to use. With the new dual pens, teacher and student or two students can work simultaneously using different attributes.
Make any flat surface interactive
Transform existing whiteboards, plain walls, and tables into interactive workspaces. Make the most of your environment with this flexible solution.
Quick start up
Simply plug in and turn on – the PC-free annotation mode means that teachers don't even need to power up their computers.
Document camera control
Connect the Epson ELPDC21 document camera to an EB-600 Series projector to easily capture and displays books, 3D objects and experiments. You can also add annotations directly to a projected live image without the need of a PC. To simplify the process you can operate the document camera from the toolbar on the projection screen.
Save lesson notes
You can save projected images to USB as jpeg files. Any annotations written over an image using PC Free Annotation can be saved as well.
Timer Function
A timer can be easily accessed from the toolbar and displayed on the screen. Whether it's answering problems or holding a group discussion, you can easily manage the time with the whole class.
Interactive multi projection
Install two EB-600 series projectors side by side and enjoy the benefits of a huge wall-size area to use as an extended whiteboard. Or, use the included Easy Interactive Tools (EIT) software to achieve a giant display on which you can create or annotate content.
WIRELESS CLASSROOMS
Dual Pen
Epson iProjection™ via optional wireless dongle
Epson iProjection is the wireless display solution for today's BYOD classrooms. With true multi-platform support, students can wirelessly display content from Chromebooks, PCs and Mac® computers, as well as iOS and Android devices.
When used in conjunction with Epson Multi-PC projection plus Moderator device management software4, up to 50 users can connect to the projector simultaneously, displaying content from as many as four at a time. It's the perfect tool for displaying a variety of content — or for comparing students' work side by side.
Networking features that take teaching to the next level
Manage up to 1,024 Epson networked displays using the included EasyMP® Monitor software or Crestron RoomView® — saves time and money
Update display firmware in-house via the network, a USB cable, or a USB flash drive — eliminates the need for external service centre repairs; saves time and money
Send updates or announcements remotely to up to 1,024 Epson networked displays using the Message Broadcasting plug-in for EasyMP Monitor
Connect your display to an access point to share it with the entire class, without running more cables
Technical Specifications
Technology / Optical
| Projection System |
3LCD Technology |
| LCD Panel |
0.59 inch with D9 |
| Light Source |
Lamp (250W) |
| Lamp Life |
Normal: 5,000 hrs, Economy: 10,000 hrs / 9,000 hrs |
| Resolution |
WXGA (HD Ready Enhanced) |
| Aspect Ratio |
16:10 |
| Contrast Ratio |
14,000:1 |
| Color Light Output |
3,500 Lumens (2,900 Lumens economy) |
| White Light Output |
3,500 Lumens (2,900 Lumens economy) |
| Keystone Correction |
Manual Vertical ±3°, Horizontal ±3° |
| Color Processing |
10-bit |
| Color Reproduction |
Up to 1.07 billion colors |
| Vertical Refresh Rate |
100 – 120 Hz |
| Throw Ratio |
0.28 – 0.37:1 |
| Zoom |
Digital, Factor: 1 – 1.35 |
| Lens |
Optical |
| Screen Size |
60" – 100" |
| Projection Distance (Wide) |
0.4 m (60") |
| Projection Distance (Tele) |
0.6 m (100") |
| F Number |
1.6 |
| Focal Length |
3.7 mm |
| Focus |
Manual |
| Offset |
6:1 |
Connectivity
| USB Display |
3-in-1: Image / Mouse / Sound |
| Interfaces |
USB 2.0-A, USB 2.0, RS-232C, Ethernet (10/100), Wireless LAN IEEE 802.11b/g/n (optional),
2 x VGA In, 1 x VGA Out, 3 x HDMI In, Composite In, 2 x RGB In, RGB Out,
MHL, Audio In (3x), Audio Out, Mic In, Sync In/Out, Jack Plug In/Out |
| Epson iProjection |
Ad-Hoc / Infrastructure |
Advanced Features
| Security |
Kensington lock, Control panel lock, Password lock, Padlock, Cable hole, Wireless LAN lock, Wireless LAN security |
| 2D Colour Modes |
Dynamic, Cinema, Presentation, sRGB, Blackboard |
| Other Features |
AV Mute Slide, Auto Brightness, Auto Input Selection, Built-in Speaker, CEC Support,
Custom Logo, Digital Zoom, Direct Power On/Off, Document Camera Compatible,
Dual Pen Support, Dynamic Lamp Control, Easy OSD Preset, Home Screen,
Interactive, Long Lamp Life, MHL AV Interface, Multi-screen Interactivity,
PC Interactive, Split-Screen, Microphone Input |
| Interactivity |
Yes – Pen and Finger Touch |
| Video Color Modes |
Blackboard, Cinema, Dynamic, Presentation, sRGB |
| Projector Control |
AMX, Crestron, Control4 |
General
| Power Consumption |
Normal: 301W, Eco: 258W, Peak: 354W, Eco Peak: 309W,
Standby: 0.37W (Energy Saving) |
| Voltage |
AC 100–240 V, 50/60 Hz |
| Dimensions (W x D x H) |
367 x 400 x 149 mm |
| Weight |
5.8 kg |
| Noise Level |
Normal: 35 dB, Economy: 30 dB, Eco2: 29 dB |
| Operating Temperature |
5 – 40°C |
| Storage Temperature |
−10 – 60°C |
| Operating Humidity |
20 – 80% |
| Storage Humidity |
10 – 90% |
| Loudspeaker |
16 W |
| Room Type / Application |
Meeting Room, Classroom |
| Positioning |
Wall Mounted |
| Color |
White / Grey |
| Warranty |
5 years Carry-in or 8,000 hours
Lamp: 5 years or 1,000 hours (whichever comes first) |
Included Software
- Easy Interactive Tools
- EasyMP Multi PC Projection
- Epson Projector Management
Compatible Operating Systems
- Windows 10, 8, 8.1
- Mac OS 10.7 – 10.10.x
- Linux
- Ubuntu 14.10 – 16.04 LTS
Optional Accessories
- Air Filter ELPAF38
- Connection and Control Box
- Document Camera
- External Speaker
- Pen Tips (Felt & Teflon)
- Wireless LAN Unit
Environmental Note
If the projector is installed in environments with heavy oil smoke, chemicals, or aroma oils, certain parts may degrade over time and risk detachment. Please contact Epson support for advice if unsure.
