Ion F-SNMP Network Management Card for F16 F18 UPS Remote Monitoring
The Ion F-SNMP Network Management Card delivers professional remote monitoring and control capabilities for your Ion F16 Line Interactive (1kVA to 3kVA) and F18 Online Double-Conversion (1kVA to 10kVA) UPS systems. Designed and supported in Australia, this SNMP web adapter enables you to manage your uninterruptible power supply via web browser from anywhere, providing real-time notifications when power issues occur and ensuring your critical equipment stays protected.
Key Features
-
Remote Web Management: Monitor and control your UPS from any web browser with intuitive interface
-
Real-Time Notifications: Receive instant alerts via email or SNMP traps when power events occur
-
Advanced Security Protocols: Supports HTTPS, SSL, SSH, SNMPv1/v2/v3, TLS 1.1/1.2, and Radius authentication
-
Event Logging: Comprehensive logging of all UPS events for troubleshooting and compliance
-
Optional Environmental Monitoring: Add the F-EMP sensor for temperature and humidity monitoring with alerts
-
3-Year Advanced Replacement Warranty: Australian-backed support with fast replacement service
Professional Remote UPS Monitoring
When you add the F-SNMP card to your Ion F16 or F18 UPS, you gain complete visibility and control over your power protection infrastructure. The card slots directly into the UPS and connects to your network via RJ45 Ethernet, with additional RS-232 and USB ports for flexible connectivity options. Perfect for server rooms, data centers, retail environments, and distributed IT installations where remote management is essential.
Advanced Security and Protocol Support
Security is paramount for network-connected devices. The F-SNMP supports the latest encryption standards including HTTPS, SSL, SSH, and SNMPv3, ensuring your UPS management traffic is protected. It's fully compatible with industry-standard protocols including RFC1628 UPS MIB, Modbus TCP/IP, IPv6, and TLS 1.1/1.2, making integration into existing network management systems seamless.
Compatible UPS Systems
-
Ion F16 Series: Line Interactive UPS from 1kVA to 3kVA (rack/tower format)
-
Ion F18 Series: Online Double-Conversion UPS from 1kVA to 10kVA (rack/tower format)
Connectivity and Interfaces
-
RJ45 Ethernet Port: Primary network connection for SNMP and web management
-
RS-232 Serial Port: Legacy serial communication and configuration
-
USB Port: Alternative management and configuration interface
-
Environmental Sensor Port: Connect optional F-EMP temperature/humidity probe
What's in the Box
- Ion F-SNMP Network Management Card
- Installation instructions
- Mounting hardware
Full Specifications
Communications and Management
| Authentication Protocols |
HTTP & HTTPS, IPv6, RFC1628 UPS MIB, SNMPv1/v2/v3, SSL & SSH, TLS 1.1/1.2, Radius, Modbus on TCP/IP |
| Network Interface |
RJ45 Ethernet (10/100 Mbps) |
| Serial Interface |
RS-232 |
| USB Interface |
USB Type A |
| Management Interface |
Web browser, SNMP, command line |
| Environmental Monitoring |
Optional F-EMP sensor (temperature & humidity) |
Compatibility
| Compatible UPS Models |
Ion F16 Series (1kVA-3kVA), Ion F18 Series (1kVA-10kVA) |
| Installation |
Internal SNMP slot in compatible UPS units |
General
| Warranty |
3 years advanced replacement warranty |
| Support |
Ion Warranty Support Line: 1300 700 805 |
| Designed in |
Australia |
Specifications are sourced from the manufacturer product page and may be updated. For the latest technical information, visit ionups.com.au or contact Ion support.
