Ion F18-IOT 1000VA Online Rack/Tower UPS with Cloud Connectivity
The Ion F18-IOT 1000VA/1000W Rack/Tower UPS delivers enterprise-grade power protection with true double conversion online topology for rack servers, network equipment, storage systems, and critical IT infrastructure. Featuring unity 1.0 power factor, this versatile 2U UPS provides clean, uninterrupted power with greater than 98% efficiency, reducing energy costs while safeguarding your equipment from data loss, corruption, and downtime. With built-in cloud connectivity and IoT monitoring, you can monitor your UPS remotely through any internet-connected device, making it ideal for modern IT and OT applications.
Key Features
-
True Double Conversion Online UPS: Pure sine wave output with zero transfer time to battery backup for maximum protection
-
Unity 1.0 Power Factor: 1000VA/1000W output delivers full power utilization (watts equal VA)
-
Cloud-Connected Monitoring: Future-proof IoT connectivity allows remote monitoring via internet-connected devices
-
High Efficiency: Greater than 98% efficiency rating cuts energy costs and reduces heat
-
Compact 2U Design: Flexible rack or tower mounting with smallest footprint in its class
-
LCD User Interface: Simplifies monitoring of load, battery, input, and output parameters
-
Scalable Battery Runtime: Optional external battery modules (EBM) for extended run time
-
3-Year Advanced Replacement Warranty: Australian-backed warranty for peace of mind
Enterprise-Grade Power Protection
The F18-IOT series utilizes true online double-conversion topology, isolating connected equipment from any power issues on the input line. This provides superior protection against surges, sags, spikes, voltage fluctuations, and complete power failures. The wide input voltage range accommodates challenging power environments, while grouped programmable outlets allow flexible power management for different equipment types.
Advanced Connectivity & Management
Stay connected to your power infrastructure with multiple communication ports and optional SNMP and relay cards. The F18-IOT features optional Wi-Fi communication modules, enabling wireless monitoring and management. Power management software is included, providing sophisticated control and automated shutdown capabilities to protect your data during extended outages.
Flexible Installation & Scalability
The 2U rack/tower convertible design offers maximum installation flexibility for server rooms, network closets, and edge computing environments. Hot-swappable batteries allow easy replacement without powering down connected equipment. The UPS automatically detects the number of external battery modules, and supports 1+1 parallel capacity up to 3 units for redundancy and increased power capacity. Optional maintenance bypass modules enable service without interruption.
Ideal Applications
Perfect for protecting rack servers, voice and data networks, storage arrays, networking equipment, IP cameras, access control systems, and other mission-critical IT and OT applications in commercial, retail, education, healthcare, and industrial environments across Australia.
What's in the Box
- Ion F18-IOT 1000VA/1000W UPS unit
- Power cord
- USB communication cable
- Tower mounting feet
- Rack mounting brackets and hardware
- User manual and warranty documentation
- Power management software
Full Specifications
| Model |
F18-IOT-1KW-RT |
| Capacity |
1000VA / 1000W |
| Power Factor |
Unity 1.0 PF |
| Topology |
True Double Conversion Online |
| Output Waveform |
Pure Sine Wave |
| Efficiency |
>98% |
| Output Outlets |
8 x IEC C13 (two groups of 4 x C13) |
| Form Factor |
2U Rack/Tower Convertible |
| Display |
LCD User Interface |
| Communication |
Multiple ports, USB, Optional SNMP, Optional Wi-Fi |
| IoT Connectivity |
Cloud monitoring capability |
| Battery |
Internal sealed lead-acid, hot-swappable |
| External Battery Support |
Yes, compatible with Ion EBM modules |
| Charging Current |
0-4A adjustable digital charger |
| Input |
Wide voltage range, dual input capable |
| Protection |
Surge, overload, short circuit protection |
| Parallel Capability |
1+1 parallel capacity up to 3 units |
| Warranty |
3 Year Advanced Replacement Warranty |
Specifications are sourced from the manufacturer product page and may be updated.
