IVSEC LX Series 8-Camera 4MP Security Kit with 8-Channel 4K NVR & 2TB HDD
The IVSEC LX Series Kit is a complete video surveillance solution featuring 8 x NC119XA 4MP IP cameras and an IVNR008XB 8-channel PoE NVR with 2TB pre-installed storage. Designed for homes, offices, and retail environments, this kit delivers crystal-clear 4-megapixel resolution, advanced Smart Motion Detection that distinguishes humans and vehicles, and powerful deterrent features including red and blue strobe lights, two-way audio, and built-in siren. With plug-and-play PoE connectivity and the free IVSEC X mobile app, setup is fast and remote monitoring is effortless.
Why You'll Love This Security System
-
Complete 8-camera kit: Everything you need in one box for comprehensive property coverage
-
4MP high-resolution cameras: Capture clear, detailed footage day and night with 25m infrared range
-
Smart Motion Detection: AI-powered human and vehicle detection reduces false alarms
-
Active deterrent features: Red and blue strobe lights, built-in siren, and two-way audio to scare off intruders
-
8-channel 4K NVR: Record up to 8 cameras with 2TB SkyHawk surveillance HDD pre-installed
-
Simple PoE installation: Power and data over a single cable per camera
-
Remote viewing: Monitor from anywhere using the free IVSEC X mobile app
NC119XA 4MP IP Camera Features
Each NC119XA camera in this kit is packed with advanced features for proactive security. The 4-megapixel turret dome design offers a 95° wide-angle view with a 2.8mm lens, ensuring excellent coverage of entryways, driveways, and outdoor areas. Full-colour night vision up to 25 metres keeps your property visible even in low light, while Smart Motion Detection with human and vehicle classification ensures you're only alerted to real threats.
The cameras feature IP66 weatherproof housing for all-weather outdoor use, Power over Ethernet (PoE) for single-cable installation, and H.265+ video compression to save storage space. Advanced deterrent features include red and blue strobe lights, a built-in microphone and speaker for two-way audio, and a loud siren that can be triggered via the mobile app or automatically.
-
Resolution: 4 Megapixels (2560 × 1440)
-
Lens: 2.8mm fixed, 95° field of view
-
Night vision: Infrared up to 25m, full-colour mode available
-
Weatherproof rating: IP66 for indoor and outdoor use
-
Smart detection: Human and vehicle classification, perimeter intrusion, line crossing, sound detection
-
Active deterrent: Red/blue strobe lights, siren, two-way audio
-
Storage: Micro SD/SDHC card slot (card not included)
-
Video compression: H.265, H.265+, H.264, H.264+
-
Power: PoE (IEEE 802.3af), 12V DC
IVNR008XB 8-Channel 4K NVR
The IVNR008XB Network Video Recorder is a powerful and compact 8-channel NVR with 8 built-in PoE+ ports, making installation simple and cable-free. It supports cameras up to 12MP resolution and features 4K HDMI output for crystal-clear local viewing. The NVR includes a 2TB SkyHawk surveillance-grade hard drive, pre-installed and ready to record, with support for up to 16TB total storage.
Advanced Intelligent Video Surveillance (IVS) features include motion detection, perimeter intrusion detection, face recognition, human and vehicle detection, line crossing detection, stationary object detection, and more. H.265+ compression dramatically reduces bandwidth and storage requirements without sacrificing video quality. Remote access is seamless via the free IVSEC X mobile app, web browser, or PC client software.
-
Channels: 8-channel, supports up to 8 IP cameras
-
Max resolution: 12MP per channel
-
PoE ports: 8 x PoE+ (IEEE 802.3at) built-in
-
Storage: 1 x SATA bay, 2TB SkyHawk HDD pre-installed (max 16TB)
-
Video output: 4K HDMI, VGA
-
Video compression: H.265+, H.265, H.264+, H.264, MJPEG
-
Recording modes: Continuous, scheduled, event-triggered (motion, IVS, PIR)
-
IVS analytics: Motion detection, perimeter intrusion, face recognition, human & vehicle detection, line crossing, stationary object, crossing counting, heat map, crowd density, queue length, license plate detection, sound detection, video tampering
-
Remote access: IVSEC X mobile app (iOS/Android), web browser, PC client (VMS/CMS)
-
Network: Gigabit Ethernet, HTTPS, DDNS, NTP, P2P (QR code setup)
Easy Installation & Remote Monitoring
This LX Series kit is designed for plug-and-play installation. Simply connect each camera to the NVR using a single Cat6 cable (not included), and the NVR automatically detects and powers the cameras via PoE. Scan the QR code on the NVR with the free IVSEC X app to enable remote viewing, push notifications, and playback from your smartphone or tablet, anywhere in the world.
Perfect For
- Home security and surveillance
- Small to medium-sized businesses and retail stores
- Offices, warehouses, and commercial properties
- Schools, childcare centres, and educational facilities
- Perimeter security and outdoor monitoring
What's in the Box
- 8 x IVSEC NC119XA 4MP IP Turret Dome Cameras
- 1 x IVSEC IVNR008XB 8-Channel PoE NVR with 2TB HDD Pre-installed
- 1 x HDMI Cable
- 1 x USB Mouse
- 1 x Power Supply for NVR
- Quick Start Guide & QR Code for Mobile App Setup
Note: Network cables (Cat5e/Cat6) are not included and must be purchased separately.
Full Specifications
NC119XA Camera Specifications
| Model |
IVSEC NC119XA |
| Camera Type |
Turret Dome IP Camera |
| Image Sensor |
1/3" 4MP CMOS |
| Resolution |
4 Megapixels (2560 × 1440) |
| Lens |
2.8mm fixed |
| Field of View |
95° (horizontal) |
| Night Vision Range |
Up to 25m (IR), full-colour mode available |
| Weatherproof Rating |
IP66 |
| Smart Detection |
Human & vehicle classification, Smart Motion Detection |
| IVS Features |
Perimeter intrusion, line crossing, sound detection |
| Active Deterrent |
Red/blue strobe lights, built-in siren, two-way audio |
| Audio |
Built-in microphone and speaker |
| Storage |
Micro SD/SDHC card slot (up to 256GB, card not included) |
| Video Compression |
H.265+, H.265, H.264+, H.264 |
| Network |
RJ45 10/100 Mbps Ethernet |
| Power |
PoE (IEEE 802.3af), 12V DC |
| Power Consumption |
Max 12W |
| Operating Temperature |
-30°C to +60°C |
| Warranty |
3 Years Australian Warranty |
IVNR008XB NVR Specifications
| Model |
IVSEC IVNR008XB-2TB |
| Channels |
8-channel |
| Max Camera Resolution |
12MP |
| Incoming Bandwidth |
76 Mbps |
| PoE Ports |
8 x PoE+ (IEEE 802.3at) |
| HDD Bays |
1 x SATA (3.5") |
| Storage Capacity |
2TB SkyHawk HDD pre-installed (max 16TB) |
| Video Output |
1 x HDMI (4K), 1 x VGA |
| Video Compression |
H.265+, H.265, H.264+, H.264, MJPEG |
| Recording Modes |
Continuous, scheduled, motion, IVS, PIR |
| IVS Analytics |
Motion detection, perimeter intrusion, face recognition, human & vehicle detection, line crossing, stationary object, crossing counting, heat map, crowd density, queue length, license plate detection, sound detection, video tampering |
| Audio |
2-way audio support (camera dependent) |
| Network |
1 x Gigabit Ethernet (RJ45) |
| USB |
2 x USB 2.0 (backup) |
| Alarm I/O |
Not specified |
| Remote Access |
IVSEC X mobile app, web browser, PC VMS/CMS client |
| Protocols |
ONVIF Profile S/G/T, HTTPS, DDNS, NTP, P2P |
| Operating Temperature |
-10°C to +55°C |
| Power Supply |
12V DC / 4A |
| Dimensions (W x D x H) |
315 × 240 × 48 mm |
| Warranty |
3 Years Australian Warranty |
Specifications are sourced from the manufacturer product page and may be updated. For the latest technical details, please visit the official IVSEC website or contact us.
