IVSEC NR316XD 16-Channel Network Video Recorder with 12MP Recording & 16 PoE+ Ports
The IVSEC NR316XD is a professional-grade 16-channel Network Video Recorder (NVR) designed for high-performance surveillance systems in commercial, retail, and enterprise environments. Supporting up to 16 IP cameras at 12-megapixel resolution, this NVR delivers crystal-clear video recording and playback with 160 Mbps bandwidth capacity for seamless 24/7 monitoring. With 16 built-in PoE+ ports, plug-and-play installation is effortless, powering cameras and transmitting data via a single CAT5/6 cable.
Key Features
-
16 Channels: Record up to 16 IP security cameras simultaneously at up to 12MP resolution per channel
-
16 x PoE+ Ports: Built-in Power over Ethernet simplifies installation and reduces cabling costs
-
Dual HDD Bays: Supports up to 32TB total storage (16TB per bay) for long-term video retention
-
H.265/H.265+ Compression: Advanced video compression reduces storage and bandwidth requirements without sacrificing quality
-
4K HDMI Output: Sharp, ultra-high-definition video display for monitoring on 4K screens
-
AI-Powered IVS: Intelligent Video Surveillance with facial detection, human and vehicle detection, intrusion alerts, line crossing detection, and more
-
ONVIF 2.6 Compatible: Works with IVSEC X series cameras and third-party IP cameras
-
Remote Access: View live or recorded footage via mobile, tablet, or PC using the IVSEC app or VMS software
Professional Surveillance for Business & Security
The NR316XD is engineered for high-demand surveillance applications, ensuring smooth operation across all 16 channels with multi-resolution support. Whether you're monitoring a retail store, warehouse, office building, or residential complex, this NVR provides the reliability and intelligence you need. The dual SATA hard drive bays support up to 16TB each, giving you a massive 32TB of total storage capacity for continuous, high-resolution recording.
Advanced Intelligent Video Analytics
With Intelligent Video Surveillance (IVS) capabilities, the NR316XD transforms passive recording into an active security platform. Features include facial recognition, human and vehicle detection, perimeter intrusion detection, line crossing detection, stationary object detection, pedestrian detection, and cross counting. These AI-powered features reduce false alerts and help security teams focus on real threats. Advanced search methods include event-triggered searches, timeline review, time-lapse, snapshot searching, and face detection searches.
Seamless Installation & Remote Management
Thanks to the 16 built-in PoE+ ports, you can connect IP cameras directly to the NVR without the need for separate power supplies or complex wiring. Each camera receives both power and data through a single Ethernet cable, dramatically simplifying installation and reducing costs. The NR316XD features an intuitive user interface and is fully ONVIF 2.6 compatible, making it easy to integrate with IVSEC X series cameras or other IP camera brands. Remote access is simple via the IVSEC mobile and desktop app, with QR code-based P2P setup for quick cloud connection, or via web interface and VMS/CMS software.
Flexible Display & Multi-Site Monitoring
The NR316XD offers flexible display modes including 1, 4, 6, 8, 9, 10, 13, 14, or 16 split views, making it easy to monitor multiple cameras and sites simultaneously. The 4K HDMI and VGA outputs guarantee sharp, clear video display for control rooms, security centres, or retail monitoring stations. This NVR is ideal for large-scale installations where high-definition video and long-term data retention are critical.
Alarm Integration & Audio Support
The NR316XD includes alarm relays (8 inputs / 1 output) for integration with external security devices such as motion sensors, door contacts, and sirens. Audio output support allows for two-way communication or audio recording when used with compatible cameras. The NVR also features USB 3.0 ports for fast video backup and export.
Connectivity & Interfaces
-
Video Output: 1 x HDMI (4K), 1 x VGA
-
Network: 16 x PoE+ RJ45 ports, 1 x LAN port
-
Storage: 2 x SATA HDD bays (up to 16TB each, HDD not included)
-
USB: USB 3.0 ports for backup and mouse
-
Alarm I/O: 8 alarm inputs, 1 alarm output
-
Audio: Audio output support
What's in the Box
- 1 x IVSEC NR316XD 16-Channel NVR
- 1 x Power adapter
- 1 x Mouse
- 1 x Quick start guide
- 1 x Mounting accessories
Full Specifications
| Model |
NR316XD |
| Channels |
16 |
| Maximum Resolution per Channel |
12MP |
| Bandwidth Capacity |
160 Mbps |
| Video Compression |
H.264, H.264+, H.265, H.265+, MJPEG |
| PoE Ports |
16 x PoE+ (Power over Ethernet) |
| Storage Bays |
2 x SATA (up to 16TB each, HDD not included) |
| Maximum Storage Capacity |
32TB |
| Video Output |
1 x HDMI (4K, 1080p, 720p), 1 x VGA |
| Display Modes |
1, 4, 6, 8, 9, 10, 13, 14, 16 split views |
| Network Interface |
1 x RJ45 10/100/1000 Mbps Ethernet |
| USB Ports |
USB 3.0 |
| Alarm I/O |
8 inputs, 1 output |
| Audio |
Audio output support |
| Recording Modes |
Continuous, Scheduled, Event Triggered (PIR, IVS, Motion, Perimeter Intrusion, Line Crossing, Stationary Object, Pedestrian Detection, Face Detection, Cross Counting) |
| Intelligent Video Surveillance (IVS) |
Facial recognition, Human and vehicle detection, Intrusion alerts, Line crossing, Stationary object detection, Pedestrian detection, Face detection, Cross counting |
| Compatibility |
ONVIF 2.6, IVSEC X series cameras, third-party IP cameras |
| Remote Access |
IVSEC mobile app (iOS/Android), VMS software (Windows/Mac), Web browser, QR code P2P setup |
| Search Methods |
Continuous, Event-triggered, Timeline, Time-lapse, Snapshot, Cross counting, Face detection |
Specifications are sourced from the manufacturer product page and may be updated.
