Lind PA1580-3903 120W Vehicle Power Adapter for Panasonic Toughbook
The Lind PA1580-3903 is a rugged 120W DC/DC power adapter designed to power Panasonic Toughbook laptops and docking stations directly from your vehicle's 11-16 VDC power source. Built for harsh mobile environments, this adapter delivers reliable, regulated power while charging the internal battery, making it ideal for public safety, utilities, field services, and mobile workforces across Australia.
Key Features
-
True 120W Continuous Power: Delivers consistent power output to demanding Panasonic Toughbook systems and docking stations
-
Bare Wire Installation: Features a 36-inch bare wire input cable and 48-inch output cable for permanent vehicle integration
-
Multiple Safety Protections: Low input voltage disconnect, high input voltage disconnect, output short circuit protection, output overcurrent protection, and internal over-temperature protection
-
Wide Compatibility: Powers Panasonic Toughbook 33, 40, 53, 54, and 55 models, plus compatible docking stations and cradles
-
Rugged Mobile Design: Engineered for dust, moisture, and high-humidity environments typical of vehicle installations
-
Automatic Shutdown Reset: Automatically resets after fault conditions are cleared
Built for Mobile Workforces
The Lind PA1580-3903 is purpose-built for professionals who rely on their Panasonic Toughbook in the field. Whether you're in law enforcement, emergency services, utilities, or transportation, this adapter provides the regulated power your rugged laptop needs while you're on the move. The bare wire design allows for clean, permanent installation in patrol cars, service vehicles, utility trucks, and ambulances.
Superior Protection & Reliability
Safety is paramount in mobile computing. This Lind adapter includes comprehensive protection features: low voltage disconnect prevents battery drain, high voltage disconnect protects against power surges, overcurrent protection guards your equipment, and thermal shutdown prevents overheating. The unit automatically resets once fault conditions are removed, ensuring minimal downtime in critical situations.
Professional Installation
The 36-inch bare wire input cable and 48-inch output cable provide flexibility for custom vehicle installations. The 11-16 VDC input range is compatible with standard automotive electrical systems. The 5.5mm × 2.5mm output connector delivers power directly to your Toughbook or docking station.
What's in the Box
- Lind PA1580-3903 120W DC/DC Power Adapter
- 36-inch bare wire input cable
- 48-inch output cable with 5.5mm × 2.5mm connector
- Installation documentation
Full Specifications
| Model |
PA1580-3903 |
| Power Output |
120W continuous |
| Input Voltage |
11-16 VDC |
| Output Voltage |
15.6 VDC (regulated) |
| Output Connector |
5.5mm × 2.5mm |
| Input Cable |
36-inch bare wire |
| Output Cable |
48-inch |
| Protection Features |
Low voltage disconnect, high voltage disconnect, short circuit protection, overcurrent protection, thermal protection |
| Compatible Models |
Panasonic Toughbook 33, 40, 53, 54, 55 & docking stations |
| Mounting Type |
Bare wire (permanent installation) |
| Operating Environment |
Dust, moisture, and high-humidity resistant |
| Warranty |
3-year limited warranty by Lind |
Specifications are sourced from the manufacturer product page and may be updated.
