MakerBot PC-ABS Filament for Method X 3D Printer Black 0.63kg
The MakerBot PC-ABS Filament is an engineering-grade 3D printing material designed for creating durable, heat-resistant prototypes and end-use parts. This black 0.63kg (1.39lb) spool combines the benefits of ABS and polycarbonate, delivering superior impact resistance and high-temperature performance for demanding industrial applications.
Why Choose PC-ABS Filament?
PC-ABS offers the perfect balance when standard ABS doesn't provide sufficient impact resistance but high heat resistance is still essential. This injection-molding grade material is widely used across automotive, railroad, and electronics industries for both prototyping and short-run production, making it ideal for functional parts that need to withstand real-world conditions.
Key Features
-
High Heat Resistance: Vicat softening temperature of 108°C (226°F) for demanding applications
-
Superior Impact Strength: 25.5 kJ/m² Charpy impact resistance, far exceeding standard ABS
-
Engineering-Grade Performance: 37 MPa tensile strength with 14% strain at break
-
Smart Spool Technology: RFID chip tracks material type, color, and remaining filament
-
Compatible with Material Extruder 1XA: Designed specifically for MakerBot Method X printers
-
Integrated Desiccant: Maintains low moisture levels for consistent print quality
Technical Performance
With a 1820 MPa E-Modulus and excellent dimensional stability, PC-ABS delivers the rigidity and accuracy needed for precision parts. The material's 1.75mm diameter ensures consistent extrusion, while Method X's circulating heated chamber eliminates warping and cracking common with high-performance thermoplastics.
Applications
Perfect for manufacturing tools, jigs, fixtures, functional prototypes, and end-use parts in industries requiring durability and heat resistance. Use PC-ABS when your application demands both the toughness of polycarbonate and the printability of ABS. For complex geometries, pair with Stratasys SR-30 dissolvable support material for clean finishes.
Compatibility
- MakerBot Method X 3D Printer
- MakerBot Method X Carbon Fiber Edition
- Material Extruder 1XA
- Not compatible with MakerBot Method standard edition
What's in the Box
- 1 × MakerBot PC-ABS Filament Spool (0.63kg / 1.39lb, Black)
- Integrated desiccant in spool
- Vacuum-sealed metalized polyester storage bag
Full Specifications
| Material Type |
PC-ABS (Polycarbonate-ABS blend) |
| Color |
Black |
| Weight |
0.63kg (1.39lb) net weight |
| Filament Diameter |
1.75mm |
| Spool Diameter |
21.8cm (8.6 in) |
| Spool Width |
4.2cm (1.65 in) |
| Tensile Strength (ISO 527) |
37 MPa (5,300 psi) |
| Strain at Break (ISO 527) |
14% |
| E-Modulus (ISO 527) |
1820 MPa (263,000 psi) |
| Impact Strength (Charpy ISO 179) |
25.5 kJ/m² (12.1 lb-ft/in²) |
| Vicat Softening Temperature (ISO 306) |
108°C (226°F) |
| Compatible Printers |
MakerBot Method X, Method X Carbon Fiber |
| Compatible Extruder |
Material Extruder 1XA |
| Manufacturer Part Number |
375-0057A |
Specifications are sourced from the manufacturer product page and may be updated.
