NetComm NF20MESH Wi-Fi 6 CloudMesh Gateway with WiFi AutoPilot
Bring the modern, adaptive Wi-Fi experience to your home with the NetComm NF20MESH CloudMesh Gateway. This Wi-Fi 6 (802.11ax) dual-band gateway utilizes WiFi AutoPilot and the Wi-Fi Analytics Platform to deliver a world-class home Wi-Fi experience with automated issue resolution and mesh network capability.
Wi-Fi 6 Performance
Wi-Fi 6 is the next generation of Wi-Fi technology. Delivering significant speed, performance and efficiency improvements, it provides up to four times more device capacity than Wi-Fi 5. These improvements enable end users to stream higher quality content with more devices on the network, while still operating at optimal performance. The NF20MESH will future-proof your Wi-Fi experience and enable smart devices throughout your modern, connected home.
WiFi AutoPilot – The Ultimate Wi-Fi Fixer
Every CloudMesh Gateway includes the CloudMesh Wi-Fi AutoPilot. Wi-Fi AutoPilot constantly scans and analyses your Wi-Fi environment. If any detrimental changes are detected, the AutoPilot automatically adjusts the gateway's Wi-Fi parameters based on a patented and weighted algorithm. It ensures that every Wi-Fi client device is connected on the best possible channel, using the fastest available band, at the perfect RF power level and at the closest Wi-Fi access point.
Mesh Network Ready
The NF20MESH comes equipped with CloudMesh technology. When wirelessly paired with a CloudMesh Satellite (NS-02), it can form a powerful Whole Home Wi-Fi Mesh network. With all the controls and settings centralized on the Gateway, it becomes the Wi-Fi Mesh master node, and Wi-Fi client devices can roam seamlessly between the Gateway and paired Satellites. Zero-touch provisioning via cloud portal or simple WPS button pairing makes setup easy.
Universal Connectivity
Featuring a Gigabit WAN port as well as VDSL2/ADSL2+ technologies, the NF20MESH will connect with FTTN, FTTB, FTTC, FTTH, HFC, and Fixed Wireless connections. Made for NBN and UFB services in Australia and New Zealand.
-
4 × Gigabit Ethernet LAN ports (RJ45 10/100/1000Mbps)
-
1 × Gigabit Ethernet WAN port (RJ45 10/100/1000Mbps)
-
1 × ADSL/VDSL DSL port (RJ11)
-
2 × VoIP phone ports (RJ11) for HD quality voice calls
-
1 × USB 3.0 port for network storage
-
WPS button for easy wireless setup
- WLAN button
- Reset button
VoIP Voice Support
The Gateway features VoIP for HD quality voice calls with the capacity to connect 2 phones via the dual RJ11 phone ports.
What's in the Box
- NetComm NF20MESH CloudMesh Gateway
- Power adapter (12V/2A)
- RJ45 Ethernet cable
- RJ11 DSL cable
- Wi-Fi security card with network name and password
- Quick start guide
Full Specifications
Wireless
| Wi-Fi Standard |
Wi-Fi 6 (IEEE 802.11ax), backwards compatible with 802.11a/b/g/n/ac |
| Frequency Bands |
Dual-band concurrent (2.4 GHz / 5 GHz) |
| Wi-Fi Speed Rating |
AX1800 |
| SSID |
Broadcast or stealth mode |
| Security |
WPA2, WPA3 |
| WPS |
Yes, via button |
DSL & WAN
| VDSL2 |
ITU-T G.993.2, supports profiles 8a, 8b, 12a, 12b, 17a, 30a, 35b |
| ADSL2+ |
ITU G.992.1/2/3/5 (G.dmt, G.lite, Annex J, L, M) |
| DSL Features |
Supports ATM and PTM, G.INP, multiple PVCs |
| DSL Connection Types |
PPPoE, PPPoA, IPoA, Static IP, Dynamic IP, Bridge |
| Ethernet WAN |
PPPoE, DHCP client, Static IP |
| NBN Compatibility |
FTTP, HFC, FTTC, FTTB, FTTN, Fixed Wireless |
Ports & Interfaces
| LAN Ports |
4 × RJ45 Gigabit Ethernet (10/100/1000Mbps) |
| WAN Port |
1 × RJ45 Gigabit Ethernet (10/100/1000Mbps) |
| DSL Port |
1 × RJ11 |
| VoIP Phone Ports |
2 × RJ11 |
| USB Port |
1 × USB 3.0 (for storage) |
| Buttons |
Reset, WPS, WLAN, Power switch |
| LED Indicators |
Power, DSL, Internet, WAN, LAN1-4, 2.4GHz, 5GHz, WPS, USB, Phone1-2 |
Advanced Features
| CloudMesh |
Yes, mesh network capable with NS-02 Satellite |
| WiFi AutoPilot |
Automated Wi-Fi optimization and issue resolution |
| Wi-Fi Analytics Platform |
Integrated support for network visibility and assurance |
| VoIP |
HD quality voice calls, 2 phone capacity |
| Edge Processing |
Low latency, real-time performance for gaming and video conferencing |
Physical Specifications
| Dimensions |
230mm (W) × 180mm (H) × 70mm (D) |
| Weight |
555g |
| Form Factor |
Vertical desktop/tabletop |
| Color |
White |
Power & Environment
| Power Input |
12V DC / 2A |
| Operating Temperature |
0°C to 40°C |
| Operating Humidity |
10% to 95% non-condensing |
| Storage Temperature |
-20°C to 70°C |
| Storage Humidity |
5% to 95% non-condensing |
Compliance & Warranty
| Certifications |
RCM, NZ Telepermit |
| Warranty |
2 years manufacturer warranty |
Specifications are sourced from the manufacturer product page and may be updated.
