Shelly Qubino Wave Pro 3 Z-Wave DIN Rail 3-Channel Smart Relay 48A
The Shelly Qubino Wave Pro 3 is a professional-grade DIN rail mountable 3-channel smart relay built on the world's leading Z-Wave technology. Designed for installation inside breaker boxes, this powerful smart switch supports up to 16A per channel (48A total) and features potential-free outputs (dry contacts), offering high flexibility in voltage compatibility and applications. Perfect for automating professional lighting, heating, cooling, and appliances in residential or commercial settings, it works seamlessly with over 4000 Z-Wave certified devices and gateways.
Why Choose the Shelly Wave Pro 3?
-
Professional Power Handling: 3 independent outputs rated at 16A each, 48A total device maximum
-
Potential-Free Dry Contacts: Flexible voltage compatibility for diverse applications
-
Z-Wave Long Range Support: Extended wireless reach up to 40m indoors (Z-Wave Plus), with signal repeater functionality
-
Ultra-Low Power Consumption: Less than 0.3W operation
-
Security 2 Authenticated: AES128 encryption for maximum network security
-
5-Year Warranty: Extended coverage for all Shelly Pro and Wave Pro devices
Smart Home Automation Made Easy
Built on the latest Z-Wave 800 Series chip technology, the Wave Pro 3 ensures stable and reliable wireless connectivity on sub-GHz frequencies without interference. Create custom scenes, schedules, and smart timers to automate lighting across multiple zones, control motorized valves for heating and cooling systems, or manage socket power delivery to reduce energy waste. The device supports SmartStart for automatic inclusion to your Z-Wave network, making setup fast and straightforward.
Versatile Applications
Ideal for commercial offices, hotels, retail spaces, and residential installations, the Shelly Wave Pro 3 enables you to:
- Automate office lighting with schedules that turn lights off after hours and on only where needed
- Control motorized valves in water distribution systems for efficient heating and cooling
- Schedule socket power delivery to cut energy consumption in half on weekends and overnight
- Manage 3-phase circuits and completely independent electrical devices
Professional Grade Protection
Enhanced with overheating, overpower, and load protection, the Wave Pro 3 is built with flame-resistant materials and designed for safe, long-term operation inside the breaker box. Compatible with both switches (default) and push-buttons, it offers flexible control options to suit your installation needs.
Universal Z-Wave Compatibility
The Shelly Wave Pro 3 works with all certified Z-Wave Plus gateways and over 4000 Z-Wave devices, regardless of brand or manufacturer. Seamlessly integrate with your existing smart home ecosystem for complete control from anywhere using your smartphone or tablet. The device acts as a Z-Wave signal repeater, extending your network range and improving overall reliability.
What's in the Box
- Shelly Qubino Wave Pro 3 Smart Relay
- User Guide
Full Specifications
Device Information
| Model |
Wave Pro 3 (EU/US) |
| Part Numbers |
QPSW-0A3X16EU (EU), QPSW-0A3X16US (US), QUSW-0A3X16EU (EU LR), QUSW-0A3X16US (US LR) |
| Product Type |
DIN Rail 3-Channel Smart Relay |
| Installation |
DIN rail mountable inside breaker box |
| Warranty |
5 years (Shelly Pro & Wave Pro series) |
Electrical Specifications
| Number of Channels |
3 independent outputs |
| Maximum Load per Channel |
16A |
| Total Device Maximum |
48A |
| Contact Type |
Potential-free outputs (dry contacts) |
| Power Consumption |
Less than 0.3W |
Wireless Connectivity
| Technology |
Z-Wave (Z-Wave 800 Series) |
| Frequency Band |
868.4 MHz (Z-Wave Plus EU), 908.4 MHz (US), 864 MHz & 868.4 MHz (Long Range) |
| Indoor Range |
Up to 40m (Z-Wave Plus), up to 80m (Z-Wave Long Range) |
| Network Topology |
Mesh (Z-Wave Plus) or Star (Z-Wave Long Range) |
| Signal Repeater |
Yes (Z-Wave Plus), No (Long Range) |
| Z-Wave Product Type ID |
0x0002 |
| Z-Wave Product ID |
0x0091 |
| Z-Wave Manufacturer ID |
0x0460 (Shelly Europe) |
Features
| Security |
Security 2 Authenticated (AES128 encryption) |
| SmartStart |
Yes (automatic inclusion) |
| Over-the-Air Updates |
Yes (OTA firmware updates) |
| Protection |
Overheating, overpower, overvoltage load protection |
| Materials |
Flame-resistant materials |
| Input Compatibility |
Switches (default) and push-buttons |
| Switch Inputs |
3 switch/push-button inputs on screw terminal |
| Compatible Devices |
Over 4000 Z-Wave certified devices and gateways |
Specifications are sourced from the manufacturer product page and may be updated.
