Shelly Wall Display X2i Smart Home Control Panel 6.95" Touchscreen - Silver
Take complete control of your smart home with the Shelly Wall Display X2i, a premium 6.95-inch touchscreen control panel featuring an ultra-fast quad-core processor, Wi-Fi 6 dual-band connectivity, and an interchangeable power base for flexible installation. Designed to fit into standard electrical wall boxes, this sleek silver panel combines style, performance, and smart automation for modern homes and offices. Compatible with Home Assistant, Google Assistant, Amazon Alexa, MQTT, and the Shelly Smart Control App, it offers complete control without cloud dependency.
Key Features
-
6.95-inch capacitive touchscreen: Responsive 5-point touch control with customisable home screen layout
-
Quad-core processor: Ultra-fast performance for smooth navigation and instant response
-
Wi-Fi 6 dual-band (2.4 GHz & 5 GHz): Advanced connectivity with Bluetooth 5.0 for stable, reliable communication
-
Interchangeable power base: Includes 1-output relay base (5A max), upgradeable to 2-output base
-
Gesture & proximity sensors: Wave to wake the screen for touchless interaction
-
Built-in LUX sensor: Automatically adjusts lighting based on ambient light levels
-
Android 11 platform: Optimised for Home Assistant dashboards and Shelly Smart Control
-
Local control: MQTT, webhooks, and Wi-Fi support without relying on the cloud
Complete Smart Home Automation
The Shelly Wall Display X2i serves as the centralised hub for your smart home, giving you instant access to lighting control, climate management, energy monitoring, and custom automation scenes. Monitor power consumption from connected Shelly devices, control appliances remotely, and create intelligent automations based on temperature, humidity, or light levels. The fully customisable interface brings all your home controls to your fingertips in one elegant panel.
Advanced Climate & Environmental Control
Pair the Wall Display X2i with Shelly BLU H&T sensors to monitor real-time temperature and humidity data. Use the panel as a thermostat interface to control heating, ventilation, and air conditioning systems. Prevent mould and mildew by automating dehumidifiers and ventilation based on environmental conditions. The integrated LUX sensor triggers connected lights automatically, optimising comfort and energy efficiency throughout your home.
Audio Integration & Notifications
Connect Bluetooth or Sonos speakers to the Shelly Wall Display X2i for enhanced audio control. Stream music, alarms, and notifications directly through your home audio system. The built-in 0.8W speaker provides audible feedback and alerts for device status and automation events.
Flexible Installation Options
Install the Shelly Wall Display X2i in a standard electrical wall box (replacing a light switch) using the included 1-output power base, or power it via USB-C cable for tabletop or portable use. The display supports both landscape and portrait orientation, adapting to your room layout and design preferences. Professional installation by a qualified electrician is recommended for hardwired installations.
Home Assistant & Platform Integration
Natively compatible with Home Assistant, the Wall Display X2i runs custom dashboards without additional apps or configuration. It also integrates seamlessly with Google Assistant, Amazon Alexa, MQTT, REST API, and Matter-compatible ecosystems. Maintain full local control and privacy with open protocols and no cloud lock-in.
What's in the Box
- Shelly Wall Display X2i (Silver)
- 1-Output Power Base (5A relay, 100-240V AC)
- Installation guide
- Mounting hardware
Full Specifications
Display
| Display Size |
6.95 inches (diagonal) |
| Display Type |
5-point capacitive color touchscreen |
| Resolution |
720 × 1280 pixels |
| Orientation |
Landscape or portrait (adjustable) |
Processor & Memory
| Processor |
Quad-core |
| Operating System |
Android 11 |
| Memory |
8 GB flash storage |
Connectivity
| Wi-Fi |
Wi-Fi 6 dual-band (2.4 GHz / 5 GHz), max RF output < 20 dBm |
| Wi-Fi Range (Indoor) |
30 m |
| Wi-Fi Range (Outdoor) |
50 m |
| Bluetooth |
Bluetooth 5.0, 2402-2480 MHz, max RF output < 4 dBm |
| Bluetooth Range (Indoor) |
10 m |
| Bluetooth Range (Outdoor) |
30 m |
| Protocols |
MQTT, REST API, webhooks, local Wi-Fi |
Sensors
| LUX Sensor |
Yes (ambient light sensor) |
| Proximity Sensor |
Yes (gesture detection) |
| G-Sensor |
Yes (orientation detection) |
Power & Relay
| Power Input (with base) |
100-240 V~ AC, 50/60 Hz |
| Power Input (USB-C) |
5V DC via USB-C cable |
| Included Power Base |
1-output relay (5A max switching current) |
| Max Switching Voltage |
240 V~ |
| Max Switching Current |
5 A |
| Optional Upgrade |
2-output power base (sold separately) |
Audio
| Built-in Speaker |
0.8 W |
| External Audio |
Bluetooth speaker or Sonos integration |
Physical Specifications
| Dimensions (H × W × D) - with base |
87 × 178 × 36 mm |
| Dimensions (H × W × D) - without base |
87 × 178 × 11 mm |
| Weight (with power base) |
292 g |
| Weight (without power base) |
246 g |
| Colour |
Silver |
| Installation |
Standard electrical wall box or USB-C powered |
Compatibility & Integration
| Smart Home Platforms |
Home Assistant, Shelly Smart Control App, Google Assistant, Amazon Alexa, Matter, MQTT |
| Compatible Sensors |
Shelly BLU H&T, Shelly BLU Motion, other Shelly devices |
| Cloud Dependency |
None (local operation supported) |
Environmental & Safety
| Operating Temperature |
0°C to +40°C |
| Max Altitude |
2000 m |
| IP Rating |
Indoor use only |
| Certification |
CE, FCC, RoHS |
Warranty & Support
| Warranty |
2 years (manufacturer warranty) |
| Device Model |
SAWD-5A1XX10EU0 |
| Bluetooth ID |
0x3005 |
Specifications are sourced from the manufacturer product page and may be updated.
