Vertiv Liebert MicroPod 2U Maintenance Bypass Switch for UPS to 3kVA

    Description

    Vertiv Liebert MicroPod 2U Maintenance Bypass Switch for UPS Systems to 3kVA

    The Vertiv Liebert MicroPod is a professional-grade maintenance bypass and power output distribution unit designed for UPS systems up to 3kVA single phase. When your critical computer systems can't afford downtime - even during scheduled maintenance - the MicroPod ensures continuous uptime by allowing manual switchover from UPS to utility power without interruption. Compatible with virtually any brand of UPS, this compact 2U rackmount unit installs with plug-and-play ease and provides peace of mind for mission-critical applications.

    Why You'll Love the Liebert MicroPod

    • Zero-Downtime Maintenance: Manually transfer connected equipment to utility power during UPS servicing or replacement without powering down critical loads
    • Universal Compatibility: Works with any brand of UPS system rated 3000VA single phase or smaller, including Liebert GXT, PSI, and third-party models
    • Fast Transfer Time: Switches between UPS and maintenance bypass mode in less than 6 milliseconds, protecting sensitive equipment
    • Plug-and-Play Installation: Supplied cords connect the utility and UPS to the MicroPod with minimal setup time
    • Flexible Mounting Options: Compact 2U height with included brackets for rack mounting in any direction
    • Multiple Output Options: Model MP2-220L features (4) EN60320/C13 outlets and (1) EN60320/C19 outlet with circuit breaker protection

    How It Works

    The Liebert MicroPod provides two modes of operation: UPS mode (normal protected operation) and Utility mode (maintenance bypass). The unit plugs into both the utility power source and your UPS, with all protected devices connected to the MicroPod's output receptacles. During normal operation, power flows through the UPS to provide battery backup and conditioned power. When maintenance is required, simply turn the rotary switch to Utility mode and the load is transferred to raw utility power, allowing you to safely remove or service the UPS without affecting connected equipment.

    Professional Features for Critical Applications

    Designed for data centres, server rooms, network closets, and telecommunications applications, the MicroPod offers enterprise-grade reliability in a compact form factor. The unit features circuit breaker protection on all output receptacles and clear LED indicators showing UPS available and utility available status. Operating temperature range of 0°C to 40°C ensures reliable performance in demanding environments.

    Ideal For

    • IT and network equipment requiring continuous uptime
    • Server rooms and data centres with scheduled UPS maintenance windows
    • Telecommunications infrastructure and edge computing deployments
    • Any application where UPS removal or servicing cannot interrupt power to critical loads
    • Facilities requiring compliance with uptime service level agreements

    What's in the Box

    • Vertiv Liebert MicroPod 2U unit (model MP2-220L)
    • Utility input power cord (EN60320/C20)
    • UPS connection jumper cord (6 foot)
    • Rack mount brackets and hardware
    • Installation and user guide

    Full Specifications

    Electrical

    Supported UPS Capacity Up to 3kVA (3000VA), single phase
    Maximum Current 16A
    Input Connection (Utility) EN60320/C20 plug
    Connection to UPS Input EN60320/C19 receptacle
    Connection to UPS Output EN60320/C20 on attached 6 foot jumper
    Output Receptacles (4) EN60320/C13 with 10A circuit breaker
    (2) EN60320/C13 with 10A circuit breaker
    (1) EN60320/C19 with 20A circuit breaker
    Transfer Time Less than 6 milliseconds
    Bypass Switch Rating 20A or 30A depending on model
    Frequency 50/60 Hz (UPS dependent)

    Mechanical

    Form Factor 2U rackmount/tower
    Dimensions (W × D × H) 394 × 77 × 88 mm (15.5 × 3.0 × 3.5 inches)
    Weight 2.0 kg (4.4 lbs)
    Mounting Options 19-inch rack mount with included brackets (any direction)

    Environmental

    Operating Temperature 0°C to 40°C (32°F to 104°F)
    Storage Temperature -20°C to +60°C (-4°F to 140°F)
    Humidity 0% to 95%, non-condensing

    Standards & Certifications

    Manufacturer Quality ISO 9001 certified
    Factory Testing Fully tested before shipment

    Specifications are sourced from the manufacturer product page and may be updated.

    Product form

    Vertiv Liebert MicroPod 2U Maintenance Bypass Switch for UPS to 3kVA

      $740.00  $715.00

      In Stock - Express Post Delivery Available (1-2 Business Days)  Mid weeks
      Monday to Friday we offer Express Post delivery
      Weekends
      We offer no delivery on weekends

        • Guaranteed secure & safe checkout.

          paypal
        • Fast shipping on all orders
        • Shipped today? Order within: Oct 18, 2026 10:00:00 +1100

        Description

        Vertiv Liebert MicroPod 2U Maintenance Bypass Switch for UPS Systems to 3kVA

        The Vertiv Liebert MicroPod is a professional-grade maintenance bypass and power output distribution unit designed for UPS systems up to 3kVA single phase. When your critical computer systems can't afford downtime - even during scheduled maintenance - the MicroPod ensures continuous uptime by allowing manual switchover from UPS to utility power without interruption. Compatible with virtually any brand of UPS, this compact 2U rackmount unit installs with plug-and-play ease and provides peace of mind for mission-critical applications.

        Why You'll Love the Liebert MicroPod

        • Zero-Downtime Maintenance: Manually transfer connected equipment to utility power during UPS servicing or replacement without powering down critical loads
        • Universal Compatibility: Works with any brand of UPS system rated 3000VA single phase or smaller, including Liebert GXT, PSI, and third-party models
        • Fast Transfer Time: Switches between UPS and maintenance bypass mode in less than 6 milliseconds, protecting sensitive equipment
        • Plug-and-Play Installation: Supplied cords connect the utility and UPS to the MicroPod with minimal setup time
        • Flexible Mounting Options: Compact 2U height with included brackets for rack mounting in any direction
        • Multiple Output Options: Model MP2-220L features (4) EN60320/C13 outlets and (1) EN60320/C19 outlet with circuit breaker protection

        How It Works

        The Liebert MicroPod provides two modes of operation: UPS mode (normal protected operation) and Utility mode (maintenance bypass). The unit plugs into both the utility power source and your UPS, with all protected devices connected to the MicroPod's output receptacles. During normal operation, power flows through the UPS to provide battery backup and conditioned power. When maintenance is required, simply turn the rotary switch to Utility mode and the load is transferred to raw utility power, allowing you to safely remove or service the UPS without affecting connected equipment.

        Professional Features for Critical Applications

        Designed for data centres, server rooms, network closets, and telecommunications applications, the MicroPod offers enterprise-grade reliability in a compact form factor. The unit features circuit breaker protection on all output receptacles and clear LED indicators showing UPS available and utility available status. Operating temperature range of 0°C to 40°C ensures reliable performance in demanding environments.

        Ideal For

        • IT and network equipment requiring continuous uptime
        • Server rooms and data centres with scheduled UPS maintenance windows
        • Telecommunications infrastructure and edge computing deployments
        • Any application where UPS removal or servicing cannot interrupt power to critical loads
        • Facilities requiring compliance with uptime service level agreements

        What's in the Box

        • Vertiv Liebert MicroPod 2U unit (model MP2-220L)
        • Utility input power cord (EN60320/C20)
        • UPS connection jumper cord (6 foot)
        • Rack mount brackets and hardware
        • Installation and user guide

        Full Specifications

        Electrical

        Supported UPS Capacity Up to 3kVA (3000VA), single phase
        Maximum Current 16A
        Input Connection (Utility) EN60320/C20 plug
        Connection to UPS Input EN60320/C19 receptacle
        Connection to UPS Output EN60320/C20 on attached 6 foot jumper
        Output Receptacles (4) EN60320/C13 with 10A circuit breaker
        (2) EN60320/C13 with 10A circuit breaker
        (1) EN60320/C19 with 20A circuit breaker
        Transfer Time Less than 6 milliseconds
        Bypass Switch Rating 20A or 30A depending on model
        Frequency 50/60 Hz (UPS dependent)

        Mechanical

        Form Factor 2U rackmount/tower
        Dimensions (W × D × H) 394 × 77 × 88 mm (15.5 × 3.0 × 3.5 inches)
        Weight 2.0 kg (4.4 lbs)
        Mounting Options 19-inch rack mount with included brackets (any direction)

        Environmental

        Operating Temperature 0°C to 40°C (32°F to 104°F)
        Storage Temperature -20°C to +60°C (-4°F to 140°F)
        Humidity 0% to 95%, non-condensing

        Standards & Certifications

        Manufacturer Quality ISO 9001 certified
        Factory Testing Fully tested before shipment

        Specifications are sourced from the manufacturer product page and may be updated.
